DFL-1000 User Manual
13
6
•
Reconnect to the web-based manager and review the system configuration to confirm that it has been
reset to the default settings.
You can restore your system settings by uploading a previously downloaded system settings text file to
the DFL-1000 NPG.
Changing to Transparent mode
Use the following procedure if you want to switch the DFL-1000 NPG from NAT/Route mode to
Transparent mode.
Changing to Transparent mode deletes all NAT/Route mode policies and addresses. In addition any routing set
in NAT mode is also deleted. This includes the default route that is part of the default NAT/Route mode
configuration.
•
Go to System > Status .
•
Select Change to Transparent Mode.
•
Select Transparent in the operation mode list.
• Select OK.
The DFL-1000 NPG changes operation mode.
• To reconnect to the web-based manager, connect to the interface configured for Transparent mode
management access and browse to https:// followed by the Transparent mode management IP
address.
By default in Transparent mode, you can connect to the internal or DMZ interface. The default
Transparent mode management IP address is 10.10.10.1. See Configuring the management interface
(Transparent mode).
Changing to NAT/Route mode
Use the following procedure if you want to switch the DFL-1000 NPG from Transparent mode to
NAT/Route mode.
Changing to NAT/Route mode deletes all Transparent mode policies and addresses. In addition any routing set
in Transparent mode is also deleted. This includes the default route that is part of the default Transparent mode
configuration.
• Go to System > Status .
• Select Change to NAT Mode.
• Select NAT/Route in the operation mode list.
• Select OK.
The DFL-1000 NPG changes operation mode.
•
To reconnect to the web-based manager, browse to the interface that you have configured for
management access using https:// followed by the IP address of the interface.
Restarting the DFL-1000 NPG
Use the following procedure to restart the DFL-1000 NPG:
• Go to System > Status .
•
Select Restart.
The DFL-1000 NPG restarts.
Shutting down the DFL-1000 NPG
Use the following procedure to shut down the DFL-1000 NPG:
