DFL-1000 User Manual
4
0
Editing addresses
Edit an address to change its IP address and netmask. You cannot edit the address name. If you need to
change an address name, you must delete the address and then add it again with a new name.
• Go to Firewall > Address .
• Select the interface with the address that you want to edit.
•
Choose an address to edit and select Edit Address
.
•
Make the required changes and select OK to save your changes.
Deleting addresses
Deleting an address removes it from an address list. After the address is removed, it can no longer be
added to policies. To delete an address that has been added to a policy, you must first remove the
address from the policy.
• Go to Firewall > Address .
• Select the interface list containing the address that you want to delete.
You can delete any listed address that has a Delete Address icon
.
• Choose an address to delete and select Delete
.
•
Select OK to delete the address.
Organizing addresses into address groups
You can organize related addresses into address groups to make it easier to add policies. For example, if
you add three addresses and then add them to an address group, you only have to add one policy for the
address group rather than three separate policies, one for each address.
You can add address groups to any interface. The address group can only contain addresses from that
interface. Address groups are available in interface source or destination address lists.
Address groups cannot have the same names as individual addresses. If an address group is included in
a policy, it cannot be deleted unless it is first removed from the policy.
• Go to Firewall > Address > Group .
• Select the interface to which to add the address group: New Int. Group, New Ext. Group, or New DMZ
Group.
• Enter a Group Name to identify the address group.
The name can contain numbers (0-9), uppercase and lowercase letters (A-Z, a-z), and the special
characters - and _. Other special characters and spaces are not allowed.
• To add addresses to the address group, select an address from the Available Addresses list and
select the right arrow to add it to the Members list.
•
To remove addresses from the address group, select an address from the Members list and select
the left arrow to remove it from the group.
•
Select OK to add the address group.
