DFL-1000 User Manual
12
9
The web-based manager lists all saved logs of the selected type, with the active log at the top of the
list. For each log, the list shows the date and time at which an entry was last added to the log, the
size of the log file, and its name.
•
To download a log file to the management computer, select Download
.
•
Select Save to download the log messages to a text file on the management computer.
Deleting all messages in an active log
Use the following procedure to delete all messages from the active traffic, or event log:
•
Go to Log&Report > Logging .
• Select Traffic Log , or Event Log.
The web-based manager lists all saved logs of the selected type, with the active log at the top of the
list. For each log, the list shows the date and time at which an entry was last added to the log, the
size of the log file, and its name.
• To delete all messages in the active log file, select Empty Log
.
• Select OK to delete the messages.
Deleting a saved log file
Use the following procedure to delete a saved traffic, or event log file:
• Go to Log&Report > Logging .
• Select
Traffic Log
, or
Event Log
.
The web-based manager lists all saved logs of the selected type, with the active log at the top of the
list. For each log, the list shows the date and time at which an entry was last added to the log, the
size of the log file, and its name.
• To delete a saved log file, select Delete
.
• Select OK to delete the log file.
Configuring alert email
You can configure the DFL-1000 NPG to send alert emails to up to three email addresses. You can
enable sending alert emails for firewall or VPN events or violations. If you have configured the DFL-1000
NPG to write log messages to an internal hard disk, you can enable sending an alert email when the disk
is almost full.
This section describes:
•
Configuring alert email
• Testing alert emails
• Enabling alert emails
Configuring alert email
•
Go to System > Network > DNS .
•
If they have not already been added, add the primary and secondary DNS server addresses provided
to you by your ISP.
Because the DFL-1000 uses the SMTP server name to connect to the mail server, it must be able to
look up this name on your DNS server.
•
Select Apply.
•
Go to Log&Report > Alert Mail > Configuration.
