DFL-1000 User Manual
1
5
About this document
This user manual describes how to install and configure the DFL-1000 NPG. This document contains the
following information:
• Getting started
describes unpacking, mounting, and powering on the DFL-1000 NPG.
•
NAT/Route mode installation
describes how to install the DFL-1000 NPG if you are planning on
running it in NAT/Route mode.
• Transparent mode installation
describes how to install the DFL-1000 NPG if you are planning on
running it in Transparent mode.
• Firewall configuration
describes how to configure firewall policies to enhance firewall protection.
• Example policies
contain some example firewall policies.
• Users and authentication
describes how to add user names to the DFL-1000 user database and
how to configure the DFL-1000 NPG to connect to a RADIUS server to authenticate users.
•
IPSec VPNs describes how to configure DFL-1000 IPSec VPN.
•
IPSec VPN configuration examples
describe how to configure DFL-1000 IPSec VPN for a number
of example VPN configurations.
•
PPTP and L2TP VPNs
describes how to configure PPTP and L2TP VPNs between the DFL-1000
NPG and a Windows client.
•
Web content filtering
describes how to configure web content filters to prevent unwanted Web
content from passing through the DFL-1000 NPG.
• Logging and reporting
describes how to configure logging and reporting to track activity through
the DFL-1000 NPG.
• Administration
describes DFL-1000 management and administrative tasks.
• The Glossary
defines many of the terms used in this document.
• Troubleshooting FAQs
help you find the information you need if you run into problems.
For more information
In addition to the DFL-1000 User Manual , you have access to the following DFL-1000 documentation:
• DFL-1000 QuickStart Guide
• DFL-1000 CLI Reference Guide
• DFL-1000 online help
Customer service and technical support
For firmware and updated product documentation, technical support information, and other resources,
please visit our web site at http://www.D-Link.com and follow the link to the support page.
You can register your DFL-1000 NPG by pointing your web browser to www.D-Link.com/support/register
and following the directions. You can also modify your registration information by going to support.D-
Link.com.
You can contact D-Link Technical Support at:
• See Technical Support
To help us provide the support you require, please provide the following information:
•
Name
