DFL-1000 User Manual
8
9
•
Configuring the remote gateway for remote clients
•
Configuring the AutoIKE key tunnel for a remote client
•
Adding source and destination addresses for a remote client VPN
•
Adding an encrypt policy for a remote client
•
Configuring the IPSec VPN client
Configuring the remote gateway for remote clients
Example remote gateway configuration shows the information required to configure the remote gateway
for the example VPN in Example VPN between a main office internal network and a remote client
.
Example remote gateway configuration
Field name Gateway information
Gateway Name
Client_gw
Remote Gateway
Static IP Address
IP Address
2.2.2.2
Mode
Main (ID Protection)
P1 Proposal
1- Encryption
DES
Authentication
MD5
DH Group
5
Keylife
600 seconds
Authentication (Pre-shared Key)
ddcHH01887d
Local ID
Blank
Nat-traversal
Enable
Keepalive Frequency
5 seconds
You can use any characters for the authentication key. The authentication key must be the same on both the
gateway and the client.
For more information about remote gateway settings, see Adding a remote gateway.
To configure the remote gateway:
•
Go to VPN > IPSEC > Remote Gateway .
•
Select New to add a remote gateway.
•
Configure the remote gateway using the information in Example remote gateway configuration
.
•
Select OK to save the remote gateway.
Configuring the AutoIKE key tunnel for a remote client
Example AutoIKE key tunnel configuration shows the information required to configure the AutoIKE key
tunnel for the example VPN in Example VPN between a main office internal network and a remote client
.
Example AutoIKE key tunnel configuration
Field name Tunnel information
Tunnel Name
Client_VPN
