DFL-1000 User Manual
14
Hub and spoke VPN
using a VPN
concentrator
You can add VPN tunnels to a VPN concentrator to create a VPN hub and spoke
configuration. A hub and spoke configuration consists of two or more VPN tunnels that
terminate at a DFL-1000 NPG. The VPN concentrator allows VPN traffic to pass from one
tunnel to the other through a central DFL-1000 hub. See Configuring a VPN Concentrator for
hub and spoke VPN.
Aggressive and
normal mode
You can select aggressive mode for any IPSec VPN gateway configuration. In Aggressive
mode, identifying information is exchanged before encryption is set up. Aggressive mode is
less secure but establishes VPN tunnels faster. See Adding a remote gateway
.
Dialup Monitor
You can monitor the status of dialup VPNs using the dialup monitor. The dialup monitor lists
the dialup remote gateways and the VPN tunnels that are active for each remote gateway. For
each tunnel, the dialup monitor lists the tunnel lifetime, timeout, Proxy ID source, and Proxy ID
destination. See Viewing dialup VPN connection status
.
IPSec Redundancy
IPSec redundancy allows you to create a redundant AutoIKE key IPSec VPN configuration to
two remote VPN gateway addresses. See Configuring IPSec redundancy
.
Local DFL-1000 user database
You can add user names to the local DFL-1000 user database. When you add a user name, you can
specify a password or that the user can be authenticated using a RADIUS server. You can then add user
names to user groups and make these user groups available for authenticating with firewall policies,
dialup VPN, PPTP VPN, and L2TP VPN. See Users and authentication
.
Multiple WAN support
You can configure the DFL-1000 NPG to have multiple connections to the Internet. Using routing and
policies the DFL-1000 multiple WAN feature supports:
•
Redundancy, using link detection. If one WAN connection fails, the DFL-1000 NPG re-routes all
traffic to and from the other WAN connection.
• Load balancing, to balance the amount of traffic routed to each WAN port.
For more information, see Configuring the DFL-1000 NPG for multiple Internet connections
.
Logging
The following logging features are new in v2.36 (see Logging and reporting):
• DFL-1000 logs are displayed with the last message at the top of the message list.
•
Messages can be cleared from event log saved to memory.
Alert email
In v2.36 you configure alert email from Logging & Reporting. You can configure the DFL-1000 NPG to
send alert email to report firewall or VPN events or violations. See Configuring alert email
.
Checksum to protect upgrade image from corruption
A Checksum added to the v2.36 firmware image guarantees its integrity during a firmware update.
New CLI commands
The command line interface has been extensively changed for v2.36. Command syntax has been
changed to be easier to use and more effective, many command names and keywords have changed,
and CLI help has been improved.
