DFL-1000 User Manual
101
Netmask
255.255.255.0 255.255.255.0 255.255.255.0 255.255.255.0
Adding encrypt policies
Use the information in tables below to add the encrypt policies.
Use the procedure Adding an encrypt policy for a remote client
.
The Main Office requires one policy to each branch office. Each branch office requires two policies on the
same tunnel. At the branch offices, the policy for the hub must be arranged in the policy list above the
policies for the spokes.
Main office encrypt policies
Field name Policy information
Main Office to Branch 1
Source
192.168.1.0
Destination
192.168.2.0
Action
Encrypt
VPN Tunnel Name
Branch1_VPN
Main Office to Branch 2
Source
192.168.1.0
Destination
192.168.3.0
Action
Encrypt
VPN Tunnel Name
Branch2_VPN
Branch Office 1 encrypt policies
Field name Policy information
Branch 1 to Main Office (policy for hub)
Source
192.168.2.0
Destination
192.168.1.0
Action
Encrypt
VPN Tunnel Name
Main_Office_VPN
Branch 1 to Branch 2
Source
192.168.2.0
Destination
192.168.3.0
Action
Encrypt
VPN Tunnel Name
Main_Office_VPN
Branch Office 2 encrypt policies
Field name Policy information
Branch 2 to Main Office
Source
192.168.3.0
Destination
192.168.1.0
Action
Encrypt
VPN Tunnel Name
Main_Office_VPN
