HKEY_LOCAL_MACHINE\System\CurrentControlSet\Services\Rasman\
Parameters
•
Add the following registry value to this key:
Value Name: ProhibitIpSec
Data Type: REG_DWORD
Value: 1
•
Save your changes and restart the computer for the changes to take effect.
You must add the ProhibitIpSec registry value to each Windows 2000-based endpoint computer
of an L2TP or IPSec connection to prevent the automatic filter for L2TP and IPSec traffic from being
created. When the ProhibitIpSec registry value is set to 1, your Windows 2000-based computer
does not create the automatic filter that uses CA authentication. Instead, it checks for a local or active
directory IPSec policy.
Connecting to the L2TP VPN
•
Start the dialup connection that you configured in the previous procedure.
•
Enter your L2TP VPN User Name and Password.
•
Select Connect.
•
In the connect window, enter the User Name and Password that you use to connect to your dialup
network connection.
This user name and password is not the same as your VPN user name and password.
Configuring a Windows XP client for L2TP
Use the following procedure to configure a client computer running Windows XP so that it can connect to
a DFL-1000 L2TP VPN.
Configuring an L2TP VPN dialup connection
•
Go to Start > Settings .
• Select Network and Internet Connections.
• Select Create a connection to the network of your workplace and select Next.
• Select Virtual Private Network Connection and select Next.
• Name the connection and select Next.
• If the Public Network dialog box appears, choose the appropriate initial connection and select Next.
• In the VPN Server Selection dialog, enter the IP address or host name of the DFL-1000 NPG to
connect to and select Next.
• Select Finish.
Configuring the VPN connection
• Right-click the icon that you have created.
• Select Properties > Security .
• Select Typical to configure typical settings.
• Select Require data encryption.
If a RADIUS server is used for authentication do not select Require data encryption. L2TP encryption is not
supported for RADIUS server authentication.
•
Select Advanced to configure advanced settings.
•
Select Settings.
