DFL-1000 User Manual
13
8
To IP
The destination IP address of the connection.
To Port
The destination port of the connection.
Expire
The time, in seconds, before the connection expires.
Clear
Stop and active communication session.
Network configuration
Go to System > Network to make any of the following changes to the DFL-1000 NPG network settings:
• Configuring the internal interface
• Configuring the external interface
• Configuring the dmz interface
• Configuring the management interface (Transparent mode)
• Setting DNS server addresses
Configuring the internal interface
To configure the internal interface:
• Go to System > Network > Interface .
• For the internal interface, select Modify
.
• Change the IP address and Netmask as required.
• Select the management Access methods for the internal interface.
HTTPS
To allow secure HTTPS connections to the web-based manager through the internal interface.
PING
If you want the internal interface to respond to pings. Use this setting to verify your installation and for
testing.
SSH
To allow secure SSH connections to the CLI through the internal interface.
SNMP
To allow a remote SNMP manager to request SNMP information by connecting to the internal interface. See
Configuring SNMP
.
•
Select OK to save your changes.
If you changed the IP address of the internal interface and you are connecting to the internal interface to
manage the DFL-1000 NPG, you must reconnect to the web-based manager using the new internal
interface IP address.
