DFL-1000 User Manual
12
6
Traffic logs are also recorded when you select Log Traffic for a firewall policy.
• Select Log All Events to record management and activity events in the event log.
Management events include changes to the system configuration as well as administrator and user
logins and logouts. Activity events include system activities, such as VPN tunnel establishment and
URL blocking.
•
Select Apply to save your log settings.
Viewing event log saved to memory
If the DFL-1000 is configured to save event log messages to memory, you can use the web-based
manager to view, search, and clear the event log messages. This section describes:
•
Viewing event log
•
Searching event log
•
Clearing event log messages
Viewing event log
Log messages are listed with the most recent message at the top. Use the following procedure to view
event log messages saved in system memory:
•
Go to Log&Report > Logging .
•
Select Event Log.
The web-based manager lists the event log messages saved to system memory.
• Scroll through the log messages to view them.
•
To view a specific line in the log, type a line number in the Go to line field and select
.
•
To navigate through the log message pages, select Go to Next Page
or Go to Previous page .
See Log message formats for a description of log message formats.
Searching event log
Use the following procedure to search event log messages saved in system memory:
• Go to Log&Report > Logging .
• Select Event Log.
•
Select
to search the messages in the selected log.
•
Select AND to search for messages that match all the specified search criteria.
•
Select OR to search for messages that match one or more of the specified search criteria.
•
Select one or more of the following search criteria:
Keyword
To search for any text in a log message. Keyword searching is case-sensitive.
Time
To search log messages created during the selected year, month, day, and hour.
• Select OK to run the search.
The web-based manager displays the messages that match the search criteria. You can scroll
through the messages or run another search.
