DFL-1000 User Manual
3
3
You can also select Insert Policy before on a policy in the list to add the new policy above a
specific policy.
•
Configure the policy:
Source
Select an address or address group that matches the source address of the packet. Before
you can add this address to a policy, you must add it to the source interface. To add an
address, see Addresses
.
Destination
Select an address or address group that matches the destination address of the packet.
Before you can add this address to a policy, you must add it to the destination interface. To
add an address, see Addresses
.
For a DMZ
->
Int, Ext
->
Int, or Ext
->
DMZ NAT mode policy, the destination can also be
a static NAT or port forwarding virtual IP that maps the destination address to a hidden
destination address on the internal or DMZ network. See Virtual IPs
.
Schedule
Select a schedule that controls when the policy is available to be matched with connections.
See Schedules
.
Service
Select a service that matches the service (port number) of the packet. You can select from a
wide range of predefined services or add custom services and service groups. See Services
.
Action
Select how the firewall should respond when the policy matches a connection attempt.
ACCEPT
Accept the connection. If you select ACCEPT, you can also configure NAT and Authentication
for the policy.
DENY
Deny the connection.
ENCRYPT
Make this policy an IPSec VPN policy. If you select ENCRYPT, you can select an AutoIKE
key or Manual Key VPN tunnel for the policy and configure other IPSec settings. For
ENCRYPT policies, service is set to ANY and authentication is not supported. See IPSec
VPNs.
NAT
Configure the policy for NAT. NAT translates the source address and the source port of
packets accepted by the policy. If you select NAT, you can also select Dynamic IP Pool and
Fixed Port.
Dynamic IP
Pool
Select Dynamic IP Pool to translate the source address to an address randomly selected from
an IP pool added to the destination interface of the policy. To add IP pools, see IP pools
.
You cannot select Dynamic IP Pool for Int
->
Ext or DMZ
->
Ext policies if the external
interface is configured using DHCP or PPPoE.
Fixed Port
Select Fixed Port to prevent NAT from translating the source port. Some applications do not
function correctly if the source port is changed. If you select Fixed Port, you must also select
Dynamic IP Pool and add a dynamic IP pool address range to the destination interface of the
policy. If you do not select Dynamic IP Pool, a policy with Fixed Port selected can only allow
one connection at a time for this port or service.
VPN Tunnel
Select a VPN tunnel for an ENCRYPT policy. You can select an AutoIKE key or Manual Key
tunnel.
Allow
inbound
Select Allow inbound so that users behind the remote VPN gateway can connect to the
source address.
Allow
outbound
Select Allow outbound so that users can connect to the destination address behind the
remote VPN gateway.
Inbound NAT
Select Inbound NAT to translate the source address of incoming packets to the DFL-1000
NPG internal IP address.
Outbound
NAT
Select Inbound NAT to translate the source address of outgoing packets to the DFL-1000
NPG external IP address.
Traffic Shaping
Traffic Shaping controls the bandwidth available to and sets the priority of the traffic
processed by the policy. Traffic Shaping makes it possible to control which policies have the
highest priority when large amounts of data are mov
ing through the DFL
-
1000 NPG. For
