D-Link DFL-1000 [98/168] Configuring the hub
![D-Link DFL-1000 [98/168] Configuring the hub](/views2/1045575/page98/bg62.png)
DFL-1000 User Manual
9
8
Example hub and spoke VPN configuration
This section contains examples for:
• Configuring the hub
• Configuring the spokes
Configuring the hub
For the Main Office (the hub), you create a remote gateway and an AutoIKE key tunnel. You also create a
VPN concentrator and add tunnels to it as members. You then add policies to direct the VPN traffic.
Use the following procedures to create the Main Office hub:
• Configuring the remote gateways
• Configuring the AutoIKE key tunnels
•
Configuring the VPN concentrator
•
Adding source and destination addresses
•
Adding encrypt policies
Configuring the spokes
For Branch 1 and Branch 2, you create remote gateways and AutoIKE key tunnels and then add the
tunnels to the VPN concentrator. You then add policies to direct the VPN traffic.
