D-Link DFL-1000 [19/168] Connecting to the web based manager
![D-Link DFL-1000 [19/168] Connecting to the web based manager](/views2/1045575/page19/bg13.png)
DFL-1000 User Manual
1
9
Off The DFL-1000 NPG is powered off.
Green The correct cable is in use, and the connected equipment has power.
Flashing green Network activity at this interface.
Internal External
DMZ
(front)
Off No link established.
Green The correct cable is in use, and the connected equipment has power.
Flashing amber Network activity at this interface.
Internal External
DMZ
interfaces
(back)
Off No link established.
Initial configuration
When the DFL-1000 NPG is first powered on, it is running in NAT/Route mode and has the basic
configuration listed in DFL-1000 NPG initial power-on settings
.
DFL-1000 NPG initial power-on settings
Operating mode
NAT/Route
User name: admin
Administrator account
Password: (none)
IP: 192.168.1.99
Internal interface
Netmask: 255.255.255.0
IP: 192.168.100.99
Netmask: 255.255.255.0
Default Gateway: 192.168.100.1
Primary DNS Server: 207.194.200.1
External interface
Manual:
Secondary DNS Server: 207.194.200.129
IP: 10.10.10.1
DMZ interface
Netmask: 255.255.255.0
Connecting to the web-based manager
The web-based manager is the primary tool for installing and configuring your DFL-1000 NPG.
Configuration changes made with the web-based manager are effective immediately without the need to
reset the firewall or interrupt service.
To connect to the web-based manager, you need:
• a computer with an ethernet connection,
• Internet Explorer version 4.0 or higher,
• a crossover cable or an ethernet hub and two ethernet cables.
To connect to the web-based manager:
•
Set the IP address of the computer with an ethernet connection to the static IP address 192.168.1.2
and a netmask of 255.255.255.0.
