DFL-1000 User Manual
14
2
If the external interface is configured using PPPoE, MTU may be negotiated by the PPPoE protocol. If this is
the case, the system may override manual MTU settings.
To change the MTU size of the packets leaving the external interface:
• Go to System > Network > Interface .
•
For the external interface, select Modify
.
•
Select Fragment outgoing packets greater than MTU.
•
Set the MTU size.
Set the maximum packet size in the range of 68 to 1500 bytes. The default MTU size is 1500.
Experiment by lowering the MTU to find an MTU size for best network performance.
Configuring the dmz interface
You can change the dmz interface IP address and Netmask and configure the access method for the dmz
interface.
To configure the dmz interface:
•
Go to System > Network > Interface .
•
For the dmz interface, select Modify
.
•
Change the IP address and Netmask as required.
•
Select the management Access methods for the dmz interface.
HTTPS
To allow secure HTTPS connections to the web-based manager through the dmz interface.
PING
If you want the dmz interface to respond to pings. Use this setting to verify your installation and for testing.
SSH
To allow secure SSH connections to the CLI through the dmz interface.
SNMP
To allow a remote SNMP manager to request SNMP information by connecting to the dmz interface. See
Configuring SNMP
.
• Select OK to save your changes.
Configuring the management interface (Transparent mode)
In Transparent mode, you can configure the management interface for management access to the DFL-
1000 NPG.
• Go to System > Network > Management .
• Change the Management IP and Mask as required.
These must be valid addresses for the network from which you will manage the DFL-1000 NPG.
• Select the management Access methods for each interface.
By default in Transparent mode, you manage the DFL-1000 NPG by connecting to the internal or dmz
interface. However, you can configure the management interface so that you can manage the DFL-
1000 NPG by connecting to any interface.
HTTPS
To allow secure HTTPS connections to the web-based manager through this interface.
PING
If you want this interface to respond to pings. Use this setting to verify your installation and for testing.
SSH
To allow secure SSH connections to the CLI through this interface.
SNMP
To allow a remote SNMP manager to request SNMP information by connecting to this interface. See
Configuring SNMP
.
•
Select Apply to save your changes.
