DFL-1000 User Manual
2
6
your internal network to the IP address of the DFL-1000 NPG internal interface. For your DMZ network,
change the default gateway address of all computers and routers connected directly to your DMZ network
to the IP address of the DFL-1000 DMZ interface. For your external network, route all packets to the DFL-
1000 NPG external interface.
If you are using the DFL-1000 NPG as the DHCP server for your internal network, configure the
computers on your internal network for DHCP.
When the DFL-1000 NPG is connected, make sure that it is functioning properly by connecting to the
Internet from a computer on your internal network. You should be able to connect to any Internet address.
Completing the configuration
Use the information in this section to complete the initial configuration of the DFL-1000 NPG.
Configuring the DMZ interface
If you are planning to configure a DMZ network, you might want to change the IP address of the DMZ
interface. Use the following procedure to configure the DMZ interface using the web-based manager.
• Log into the web-based manager.
• Go to System > Network > Interface .
• For the dmz interface, select Modify
.
• Change the IP address and Netmask as required.
• Select Apply.
Setting the date and time
For effective scheduling and logging, the DFL-1000 NPG date and time should be accurate. You can
either manually set the DFL-1000 NPG time or you can configure the DFL-1000 NPG to automatically
keep its time correct by synchronizing with a Network Time Protocol (NTP) server.
To set the DFL-1000 NPG date and time, see Setting system date and time
.
