DFL-1000 User Manual
11
2
•
Select Challenge Handshake Authentication Protocol (CHAP).
•
Make sure that none of the other settings are selected.
•
Select the Networking tab.
•
Make sure that the following options are selected:
TCP/IP
QoS Packet Scheduler
• Make sure that the following options are not selected:
File and Printer Sharing for Microsoft Networks
Client for Microsoft Networks
Disabling IPSec
• Select the Networking tab.
•
Select Internet Protocol (TCP/IP) properties.
•
Double-click the Advanced tab.
•
Go to the Options tab and select IP security properties.
•
Make sure that Do not use IPSEC is selected.
•
Select OK and close the connection properties window.
The default Windows XP L2TP traffic policy does not allow L2TP traffic without IPSec encryption. You can
disable default behavior by editing the Windows XP Registry as described in the following steps. See the
Microsoft documentation for editing the Windows Registry.
• Use the registry editor (regedit) to locate the following key in the registry:
HKEY_LOCAL_MACHINE\System\CurrentControlSet\Services\Rasman\
Parameters
•
Add the following registry value to this key:
Value Name: ProhibitIpSec
Data Type: REG_DWORD
Value: 1
•
Save your changes and restart the computer for the changes to take effect.
You must add the ProhibitIpSec registry value to each Windows XP-based endpoint computer of an
L2TP or IPSec connection to prevent the automatic filter for L2TP and IPSec traffic from being created.
When the ProhibitIpSec registry value is set to 1, your Windows XP-based computer does not create
the automatic filter that uses CA authentication. Instead, it checks for a local or active directory IPSec
policy.
Connecting to the L2TP VPN
•
Connect to your ISP.
•
Start the VPN connection that you configured in the previous procedure.
•
Enter your L2TP VPN User Name and Password.
•
Select Connect.
•
In the connect window, enter the User Name and Password that you use to connect to your dialup
network connection.
This user name and password is not the same as your VPN user name and password.
