DFL-1000 User Manual
134
•
Make sure that the internal interface of the DFL-1000 NPG is connected to the same network as the
TFTP server.
• To confirm that you can connect to the TFTP server from the DFL-1000 NPG, use the following
command to ping the computer running the TFTP server. For example, if the TFTP server's IP
address is 192.168.1.168:
execute ping 192.168.1.168
• Enter the following command to restart the DFL-1000 NPG:
execute reboot
As the DFL-1000 NPG reboots, messages similar to the following appear:
BIOS Version 2.2
Serial number: FGT2002801012243
SDRAM Initialization.
Scanning PCI Bus...Done.
Total RAM: 256M
Enabling Cache...Done.
Allocating PCI Resources...Done.
Zeroing IRQ Settings...Done.
Enabling Interrupts...Done.
Configuring L2 Cache...Done.
Boot Up, Boot Device Capacity=62592k Bytes.
Press Any Key To Download Boot Image.
...
• Quickly press any key to interrupt system startup.
The following message appears:
Enter TFTP Server Address [192.168.1.168]:
You only have 3 seconds to press any key. If you do not press any key soon enough, the DFL-1000 NPG
reboots and you must log in and repeat the
execute reboot
command.
• Type the address of the TFTP server and press Enter.
The following message appears:
Enter Local Address [192.168.1.188]:
• Type the address of the internal interface of the DFL-1000 NPG and press Enter.
The following message appears:
Enter File Name [image.out]:
•
Enter the firmware image file name and press Enter.
The TFTP server uploads the firmware image file to the DFL-1000 NPG and messages similar to the
following appear:
Total 7682959 Bytes Data Is Downloaded.
Testing The Boot Image Now.
Total 32768k Bytes Are Unzipped.
Do You Want To Save The Image? [Y/n]
•
Type
Y
.
Programming The Boot Device Now.
................................
Read Boot Image 548405 Bytes.
Initializing Firewall...
DFL-1000 login:
The installation might take a few minutes to complete.
