DFL-1000 User Manual
4
2
AOL AOL instant messenger protocol. tcp 5190-5194
BGP Border Gateway Protocol routing protocol. tcp 179
DHCP-Relay DHCP relay service. udp 67
tcp 53
DNS Domain name servers for looking up domain names.
udp 53
FINGER Finger service. tcp 79
FTP FTP service for transferring files. tcp 21
GOPHER Gopher communication service. tcp 70
H323
H.323 multimedia protocol. Can be used for IP telephony through the
firewall.
tcp 1720, 1503
HTTP HTTP service for connecting to web pages. tcp 80
HTTPS SSL service for secure communications with web servers. tcp 443
IKE
AutoIKE Internet key exchange service. You can add policies with service
set to IKE to control IPSec connections through the firewall.
udp 500
IMAP IMAP email protocol for reading email from an IMAP server. tcp 143
Internet-
Locator-Service
An LDAP-related service for locating user addresses. tcp 389
IRC Internet relay chat for connecting to chat groups. tcp 6660-6669
L2TP L2TP VPN service. tcp 1701
LDAP LDAP directory lookup service. tcp 389
NetMeeting NetMeeting multimedia conferencing service. tcp 1720
NFS Network file services for sharing files. tcp 111, 2049
NNTP Protocol for transmitting Usenet news. tcp 119
NTP
Network time protocol for synchronizing a computer's time with a time
server.
tcp 123
OSPF Open Shortest Path First (OSPF) routing protocol. 89
PC-Anywhere For remote access to a PC. udp 5632
PING For testing connections to other computers. icmp 8
POP3 POP3 email protocol for downloading email from a POP3 server. tcp 110
PPTP PPTP VPN service. tcp 1723
QUAKE For connections used by the popular Quake multi-player computer game. udp
26000,
27000,
27910,
27960
RAUDIO For streaming real audio multimedia traffic. udp 7070
RLOGIN Rlogin service for remotely logging into a server. tcp 513
RIP Routing Information Protocol. udp 520
SMTP For sending mail between email servers on the Internet. tcp 25
tcp 161-162
SNMP For communicating system status information.
udp 161-162
SSH SSH service for secure connections to computers for remote management. tcp 22
