DFL-1000 User Manual
4
8
•
Select New to add a virtual IP.
•
Enter a Name for the virtual IP.
The name can contain numbers (0-9), uppercase and lowercase letters (A-Z, a-z), and the special
characters - and _. Other special characters and spaces are not allowed.
•
Select the virtual IP External Interface. You can select external or dmz.
external
To map an Internet address to an internal or DMZ address. If you select external, the static NAT
virtual IP can be added to Ext
->
Int and Ext
->
DMZ policies.
dmz
To map a DMZ address to an internal address. If you select dmz, the static NAT virtual IP can be
added to DMZ
->
Int policies.
•
Make sure Type is set to Static NAT.
• In the External IP Address field, enter the external IP address to be mapped to an address on the
more secure network.
For example, if the virtual IP provides access from the Internet to a web server on your DMZ or
internal network, the external IP address must be a static IP address obtained from your ISP for your
web server. This address must be a unique address that is not used by another host and cannot be
the same as the IP address of the External Interface selected in step Select the virtual IP External
Interface. You can select external or dmz.. However, this address must be routed to this interface.
• In the Map to IP field, enter the real IP address on the more secure network, for example, the IP
address of a web server on your DMZ network.
If you enter an address on the same subnet as the internal interface, the virtual IP can be added to
Ext
->
Int or DMZ
->
Int policies.
If you enter an address on the same subnet as the DMZ interface, the virtual IP can be added to Ext
->
DMZ policies.
The firewall translates the source address of outbound packets from the host with the Map to IP address
to the virtual IP External IP Address, instead of the firewall external address.
•
Select OK to save the virtual IP.
You can now add the virtual IP to firewall policies.
Firewall policies to which you can add virtual IPs
External interface Map to IP Firewall policy
Same subnet as the internal interface. Ext -> Int
external
Same subnet as the DMZ interface. Ext -> DMZ
dmz
Same subnet as the internal interface. DMZ -> Int
