Ryobi RCS2040 [20/248] English original instructions

Deutsch (Übersetzung der originalen Anleitungen)

English (Original instructions)

SPECIAL PRODUCT FEATURES

 The product is using a special safety wrap-spring

chain break mechanism to stop the chain within one

tenth of a second if the chainbrake is engaged or the

trigger is released.

 The saw chain’s safety drive links are designed to

reduce the risk of kickback.

 Large chain brake element. In case of a “kickback,

the chain brake is pushed forward” by the back of the

operator’s hand and trips the quick brake of the chain

saw.

 The lock-off Switch with lock to protect against

unintentional start of the chain saw.

 The unique Ryobi Live tool indicator™ indicate the

good connection with the power supply.

COMMISSIONING

Assembling the chain bar and saw chain

Pull the mains plug out of the socket. Wear

protective gloves.

 Unscrew the knob w/nut and remove the sprocket

cover. (Fig. 3)

 The saw chain should face in the direction of chain

rotation. If they face backwards, turn the loop over.

(Fig. 4)

 Place the chain drive links into the bar groove. (Fig.

 Position the chain so there is a loop at the back of the

bar.

 Hold the chain in position on the bar and place the

loop around the sprocket and make sure it is correctly

mounted. (Fig.6)

 Swing the chain tension adjust knob, turn the chain

tensioning bolt clockwise until the saw chain is

correctly tensioned. While the bolt is being tightened,

the chain bar must then be pushed upwards, check

chain tension again, do not tension the chain too

tightly (Fig. 7)

 Replace the sprocket cover on top and tighten gently

with the knob w/nut.

© the saw chain is correctly tensioned if, in the

middle of the cutter, it can be lifted 3mm to 4mm from the

cutter upper edge. Starting the saw again with a new saw

chain, allow it to run in for 2~3 minutes.

Q\©

After the run-in time, check the chain tension and

retighten the chain if necessary.

Chain&Bar lubricant

The chain saws are delivered without any oil in the

oiltank. Prior to initial operation of the machine, the oil

tank must be filled with lubricating oil.

Ryobi bar and chain lubricant permits chain saw

operation at temperatures as low as -15°C.

To refill the chain & bar lubricant the cap on top of the

oiltank needs to be removed. When filling the oil in,

ensure that no dirt gets into the oil tank. The oil level can

be monitored at the oil sight gauge. One filling of the oil

tank (capacity 0.2l) is sufficient for 25~40 minutes chain

saw operation.

Checking chain lubrication

If the saw chain is running dry (i.e. without lubricant), the

cutter and saw chain can be damaged. It is therefore

essential to check the oil level in the oil sight gauge

frequently and every time before starting to use the chain

saw.

CHAIN & BAR INFORMATION

Model Chain Bar

RCS1835

Carlton N1C-BL-52E SK B Carlton 14-10W-MHC UNB Y

Oregon 91PJ052X Oregon 140SDEA041

Oregon 91PJ052X Carlton 14-10W-MHC UNB Y

Tri-link JL9d-3*52 Tri-link DCR14B-050-3/8LP-52-B

RCS2040

Carlton N1C-BL-56E SK B Carlton 16-10W-N156-MHC

Oregon 91PJ056X Oregon 160SDEA041

Tri-link JL9d-3 x 56 Tri-link DCR16C-050-Y56LD

Note
