Basic Control SiBE37-701_B
113 Function
REYQ26PY1, 28PY1 (10/12+16HP)
(To increase Step No.)
STEP
No.
unit 1
INV
unit 2
INV
STD
1 52Hz 52Hz
2 56Hz 56Hz
3 62Hz 62Hz
4 66Hz 66Hz
5 70Hz 70Hz
6 74Hz 74Hz
7 80Hz 80Hz
8 88Hz 88Hz
9 92Hz 92Hz
10 96Hz 96Hz
11 104Hz 104Hz
12 110Hz 110Hz
13 116Hz 116Hz
14 124Hz 124Hz
15 132Hz 132Hz
16 144Hz 144Hz
17 158Hz 158Hz
18 166Hz 166Hz
19 176Hz 176Hz
20 80Hz 80Hz ON1
21 88Hz 88Hz ON1
22 96Hz 96Hz ON1
23 104Hz 104Hz ON1
24 116Hz 116Hz ON1
25 124Hz 124Hz ON1
26 132Hz 132Hz ON1
27 88Hz 88Hz ON2
28 96Hz 96Hz ON2
29 104Hz 104Hz ON2
30 124Hz 124Hz ON2
31 144Hz 144Hz ON2
32 92Hz 92Hz ON3
33 104Hz 104Hz ON3
34 116Hz 116Hz ON3
35 124Hz 124Hz ON3
36 144Hz 144Hz ON3
37 158Hz 158Hz ON3
38 166Hz 166Hz ON3
39 176Hz 176Hz ON3
40 188Hz 188Hz ON3
41 202Hz 202Hz ON3
42 210Hz 210Hz ON3
Initial step
Notes:
1. INV : Inverter compressor
STD : Standard compressor
Figures after ON represent the number of STD compressors in operation.
2. “Master unit”, and “slave unit” in this section are the names for control, and they will be transferred according to the
priority of rotation system.
3. Depending on the operating conditions of compressors, the compressors may run in patterns other than those
aforementioned.
(To decrease Step No.)
STEP
No.
unit 1
INV
unit 2
INV
STD
1 52Hz
2 56Hz
3 62Hz
4 68Hz
5 74Hz
6 80Hz
7 88Hz
8 96Hz
9 104Hz
10 52Hz 52Hz
11 56Hz 56Hz
12 62Hz 62Hz
13 66Hz 66Hz
14 70Hz 70Hz
15 74Hz 74Hz
16 80Hz 80Hz
17 88Hz 88Hz
18 92Hz 92Hz
19 96Hz 96Hz
20 104Hz 104Hz
21 110Hz 110Hz
22 116Hz 116Hz
23 124Hz 124Hz
24 132Hz 132Hz
25 52Hz 52Hz ON1
26 62Hz 62Hz ON1
27 68Hz 68Hz ON1
28 74Hz 74Hz ON1
29 80Hz 80Hz ON1
30 88Hz 88Hz ON1
31 96Hz 96Hz ON1
32 104Hz 104Hz ON1
33 52Hz 52Hz ON2
34 62Hz 62Hz ON2
35 74Hz 74Hz ON2
36 88Hz 88Hz ON2
37 96Hz 96Hz ON2
38 52Hz 52Hz ON3
39 62Hz 62Hz ON3
40 74Hz 74Hz ON3
41 92Hz 92Hz ON3
42 104Hz 104Hz ON3
43 116Hz 116Hz ON3
44 124Hz 124Hz ON3
45 144Hz 144Hz ON3
46 158Hz 158Hz ON3
47 166Hz 166Hz ON3
48 176Hz 176Hz ON3
49 188Hz 188Hz ON3
50 202Hz 202Hz ON3
51 210Hz 210Hz ON3
REYQ 30PY1, 32PY1 (14/16+16HP)
(To increase Step No.)
STEP
No.
unit 1
INV
unit 2
INV
STD
1 52Hz 52Hz
2 56Hz 56Hz
3 62Hz 62Hz
4 66Hz 66Hz
5 70Hz 70Hz
6 74Hz 74Hz
7 80Hz 80Hz
8 88Hz 88Hz
9 92Hz 92Hz
10 96Hz 96Hz
11 104Hz 104Hz
12 110Hz 110Hz
13 116Hz 116Hz
14 124Hz 124Hz
15 132Hz 132Hz
16 144Hz 144Hz
17 158Hz 158Hz
18 166Hz 166Hz
19 176Hz 176Hz
20 80Hz 80Hz ON1
21 88Hz 88Hz ON1
22 96Hz 96Hz ON1
23 104Hz 104Hz ON1
24 116Hz 116Hz ON1
25 124Hz 124Hz ON1
26 132Hz 132Hz ON1
27 88Hz 88Hz ON2
28 96Hz 96Hz ON2
29 104Hz 104Hz ON2
30 124Hz 124Hz ON2
31 144Hz 144Hz ON2
32 92Hz 92Hz ON3
33 104Hz 104Hz ON3
34 116Hz 116Hz ON3
35 124Hz 124Hz ON3
36 144Hz 144Hz ON3
37 96Hz 96Hz ON4
38 104Hz 104Hz ON4
39 116Hz 116Hz ON4
40 124Hz 124Hz ON4
41 144Hz 144Hz ON4
42 158Hz 158Hz ON4
43 166Hz 166Hz ON4
44 176Hz 176Hz ON4
45 188Hz 188Hz ON4
46 202Hz 202Hz ON4
47 210Hz 210Hz ON4
Initial step
(To decrease Step No.)
STEP
No.
unit 1
INV
unit 2
INV
STD
152Hz
256Hz
362Hz
468Hz
574Hz
680Hz
788Hz
896Hz
9 104Hz
10 52Hz 52Hz
11 56Hz 56Hz
12 62Hz 62Hz
13 66Hz 66Hz
14 70Hz 70Hz
15 74Hz 74Hz
16 80Hz 80Hz
17 88Hz 88Hz
18 92Hz 92Hz
19 96Hz 96Hz
20 104Hz 104Hz
21 110Hz 110Hz
22 116Hz 116Hz
23 124Hz 124Hz
24 132Hz 132Hz
25 52Hz 52Hz ON1
26 62Hz 62Hz ON1
27 68Hz 68Hz ON1
28 74Hz 74Hz ON1
29 80Hz 80Hz ON1
30 88Hz 88Hz ON1
31 96Hz 96Hz ON1
32 104Hz 104Hz ON1
33 52Hz 52Hz ON2
34 62Hz 62Hz ON2
35 74Hz 74Hz ON2
36 88Hz 88Hz ON2
37 96Hz 96Hz ON2
38 52Hz 52Hz ON3
39 62Hz 62Hz ON3
40 74Hz 74Hz ON3
41 96Hz 96Hz ON3
42 104Hz 104Hz ON3
43 52Hz 52Hz ON4
44 62Hz 62Hz ON4
45 74Hz 74Hz ON4
46 96Hz 96Hz ON4
47 104Hz 104Hz ON4
48 116Hz 116Hz ON4
49 124Hz 124Hz ON4
50 144Hz 144Hz ON4
51 158Hz 158Hz ON4
52 166Hz 166Hz ON4
53 176Hz 176Hz ON4
54 188Hz 188Hz ON4
55 202Hz 202Hz ON4
56 210Hz 210Hz ON4
Three-unit multi system
