SiBE37-701_B Troubleshooting (OP: Unified ON/OFF Controller)
Troubleshooting 390
[Check 10] Check for causes of wet operation.
Referring to the Fault Tree Analysis (FTA) shown below, identify faulty points.
Refrigerant accumulation
←
Refer to information in the [Check 6]
section.
Overcharge of refrigerant
Faulty control
of superheated
degree
[Cooling]
Indoor unit
electronic
expansion
valve opens too
much. (*1)
Faulty indoor
unit electronic
expansion valve
Faulty control
Faulty outdoor
unit electronic
expansion valve
Faulty control
Wet operation
[Heating]
Outdoor unit
electronic
expansion
valve opens too
much. (*2)
Degraded
evaporation
capacity
Dirty evaporator
Reduced
air quantity
Reduced
fan output
Increased
resistance
in air
passage
Faulty crankcase heater
Frequent ON/OFF of compressor
Faulty valve coil
Faulty valve body
Faulty indoor unit
gas pipe thermistor
Faulty indoor unit
liquid pipe thermistor
Faulty control PCB
Faulty valve coil
Faulty valve body
Faulty power pressure sensor
Faulty suction pipe thermistor
Faulty control PCB
Faulty fan motor
Faulty control PCB
(including faulty
capacity setting)
Dirty filter
Obstacles
← Are there any obstacles in the air
passage?
*1: "Superheated degree control" in cooling operation is exercised with the indoor unit electronic expansion valve.
*2: "Superheated degree control" in heating operation is exercised with the outdoor unit electronic expansion valve
(EV1).
*3: Guideline of superheated degree to judge as wet operation
(1)Suction gas superheated degree: Not more than 3°C; (2)Discharge gas superheated degree: Not more than
15°C, except immediately after compressor starts up or is running under drooping control.
(Use the values shown above as a guideline. Even if the superheated degree falls in the range, the compressor
may be normal depending on other conditions.)
← Does the air filter get clogged?
← Can the fan motor be rotated by
hand?
Does the fan motor coil have
normal resistance and
insulation?
← Does the heat exchanger get clogged?
← Is the pressure reading of the service
checker corresponding to the actual
measurement of the sensor?
← Is the connector correctly connected?
Does the thermistor have normal
resistance characteristics?
← Is the connector correctly connected?
Does the thermistor have normal
resistance characteristics?
← Are the voltage characteristics normal?
← Does the valve coil have normal
resistance and insulation?
(Refer to information in the [Check 11]
section.)
← Is the connector correctly connected?
Are the thermistor resistance
characteristics normal?
← Is the connector correctly connected?
Are the thermistor resistance
characteristics normal?
← Does the valve coil have normal
resistance and insulation?
(Refer to information in the [Check 11]
section.)
