Specifications SiBE37-701_B
23 Specifications
Roundflow Ceiling Mounted Cassette
1-1 TECHNICAL SPECIFICATIONS FXFQ63P8VEB FXFQ80P8VEB FXFQ100P8VEB FXFQ125P8VEB
Capacity Cooling kW 7.1 9.0 11.2 14.0
Heating kW 8.0 10.0 12.5 16.0
Power Input
(50Hz)
Cooling kW 0.095 0.120 0.173 0.258
Heating kW 0.114 0.108 0.176 0.246
Power Input
(60Hz)
Cooling kW 0.094 0.119 0.172 0.257
Heating kW 0.114 0.108 0.176 0.246
Casing Material Galvanised steel
Dimensions Packing Height mm 220 262 262 304
Width mm 882
Depth mm 882
Unit Height mm 204 246 246 288
Width mm 840
Depth mm 840
Weight Unit kg 21 24 24 26
Packed Unit kg 26 28 28 31
Dimensions Length Inside mm 2,096
Outside mm 2,152
Heat
Exchanger
Dimensions
Nr of Rows 2
Fin Pitch mm 1.2
Nr of Passes 7 9 9 11
Face Area m² 0.357 0.446 0.446 0.535
Nr of Stages 8 10 10 12
Fin Fin type Cross fin coil (Multi louver fins and Hi-XSS tubes)
Fan Type Turbo fan
Quantity 1
Airflow Rate Cooling High m³/min 16.5 23.5 26.5 33.0
Low m³/min 11.0 14.5 17.0 20.0
Heating High m³/min 17.5 23.5 28.0 33.0
Low m³/min 12.0 14.5 17.5 20.0
Fan Motor Model QTS48D11M QTS48C15M QTS48C15M QTS48C15M
Steps 2
Output
(high)
W 56 120 120 120
Refrigerant Name R-410A
Sound level Cooling Sound
power
(nominal)
dBA52555861
Cooling Sound
Pressure
HighdBA34384144
LowdBA29323334
Heating Sound
Pressure
HighdBA36384244
LowdBA30323434
Piping
connections
Liquid
(OD)
Type Flare connection
Diameter mm 9.52
Gas Type Flare connection
Diameter mm 15.9
Drain Diameter mm VP25 (I.D. 25/O.D. 32)
Heat Insulation Foamed polystyrene/foamed polyethylene
Sound absorbing insulation (Foamed Polyurethane)
Decoration
Panel
Model BYCQ140CW1 / BYCQ140CW1W
Colour RAL9010
Dimensions
Height mm 50
Width mm 950
Depth mm 950
Weight kg 5.5
Air Filter Resin net with mold resistance
