Specifications SiBE37-701_B
29 Specifications
1-1 TECHNICAL SPECIFICATIONS FXCQ63M8V3B FXCQ80M8V3B FXCQ125M8V3B
Nominal
Capacity
Cooling kW 7.10 9.00 14.00
Heating kW 8.00 10.00 16.00
Power input
(Nominal)
Cooling kW 0.161 0.209 0.256
Heating kW 0.126 0.176 0.223
Casing Colour Non painted
Material Galvanised steel
Dimensions Packing Height mm 405 405 405
Width mm 1460 1808 1808
Depth mm 665 645 645
Unit Height mm 305 305 305
Width mm 1180 1670 1670
Depth mm 600 600 600
Weight Unit kg 35 47 48
Packed Unit kg 42 55 56
Required Ceiling Void mm 350 350 350
Heat
Exchanger
Dimensions
Length mm 875 × 2 1365 1365
Nr of Rows 2 × 2
Fin Pitch mm 1.50 1.50 1.50
Nr of Passes 6 × 2 5 × 2 6
Face Area m² 0.184 × 2 0.287 × 2 0.287 × 2
Nr of Stages 10 × 2
Empty Tube Plate
Hole
8
Tube type Hi-XSS (7)
Fin Fin type Symmetric waffle louvre
Treatment Hydrophilic
Fan Type Sirocco fan
Quantity 2 3 3
Airflow Rate Cooling High m³/min 16.5 26.0 33.0
Low m³/min 13.0 21.0 25.0
Heating High m³/min 16.5 26.0 33.0
Low m³/min 13.0 21.0 25.0
Fan Motor Quantity 1 1 1
Steps Phase cut control
Output
(high)
W30 50 85
Drive Direct drive
Refrigerant Name R-410A
Sound Level Cooling Sound
power
(nominal)
dBA 52.0 54.0 60.0
Cooling Sound
Pressure
High dBA 38.0 40.0 45.0
Low dBA 33.0 35.0 39.0
Heating Sound
Pressure
High dBA 38.0 40.0 45.0
Low dBA 33.0 35.0 39.0
Piping
connections
Liquid
(OD)
Type Flare connection
Diameter mm 9.5 9.5 9.5
Gas Type Flare connection
Diameter mm 15.9 15.9 15.9
Drain Diameter mm 32 32 32
Heat Insulation Both liquid and gas pipes
Decoration
Panel
Model BYBC63GJW1 BYBC125GJW1 BYBC125GJW1
Colour White (10Y9/0.5)
Dimensions
Height mm 53 53 53
Width mm 1430 1920 1920
Depth mm 680 680 680
Weight kg 9.5 12.0 12.0
Drain-up Height mm 600 600 600
