SiBE37-701_B Specifications
Specifications 26
1-2 ELECTRICAL SPECIFICATIONS FXZQ20M9V1B FXZQ25M9V1B FXZQ32M9V1B FXZQ40M9V1B FXZQ50M9V1B
Power
Supply
Name V1
Phase 1~
Frequency Hz 50
Voltage V 220-240
Current Minimum circuit amps
(MCA)
A 0.8 0.8 0.8 0.8 0.9
Maximum fuse amps
(MFA)
A15
Full load amps (FLA) A 0.6 0.6 0.6 0.6 0.7
Voltage
range
Minimum V -10%
Maximum V +10%
Notes Voltage range : units are suitable for use on electrical systems where voltage supplied to unit terminals is not below or
above listed range limits.
Maximum allowable voltage range variation between phases is 2%.
MCA/MFA : MCA = 1.25 × FLA
MFA is smaller than or equal to 4 × FLA
Next lower standard fuse rating minimum 15A
Select wire size based on the MCA
Instead of a fuse, use a circuit breaker
