SiBE37-701_B Specifications
Specifications 12
Notes:
★
1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
★
2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
★
3 Indoor temp. : 20°CDB / outdoor temp. : 7°CDB, 6°CWB / Equivalent piping length : 7.5m, level
difference : 0m.
Model Name REYQ16PY1B
★
1 Cooling Capacity (19.5°CWB)
kcal / h 40,000
Btu / h 159,000
kW 46.5
★
2 Cooling Capacity (19.0°CWB) kW 45.0
★
3 Heating Capacity
kcal / h 43,000
Btu / h 171,000
kW 50.0
Casing Color
Y1 Type Ivory White 5Y7.5/1
Y1E Type Light Camel 2.5Y6.5/1.5
Dimensions: (H×W×D) mm 1680×1300×765
Heat Exchanger Cross Fin Coil
Comp.
Type Hermetically Sealed Scroll Type
Piston Displacement m³/h 16.90+16.90
Number of Revolutions r.p.m 7980, 7980
Motor Output×Number
of Units
kW 4.4+4.4
Starting Method Soft Start
Fan
Type Propellor Fan
Motor Output kW 0.75×2
Airflow Rate
I/s 4,000
m³/min 240
Drive Direct Drive
Connecting
Pipes
Liquid Pipe
φ
12.7 C1220T (Brazing Connection)
Suction Gas Pipe
φ
28.6 C1220T (Brazing Connection)
High and Low Pressure Gas Pipe
φ
22.2 C1220T (Brazing Connection)
Pressure Equalizer Tube —
Mass (Weight) kg 339
Safety Devices High Pressure Switch, Fan Driver Overload Protector, Overcurrent Relay, Inverter Overload Protector
Defrost Method Deicer
Capacity Control % 10~100
Refrigerant
Refrigerant Name R-410A
Charge kg 11.1
Control Electronic Expansion Valve
Refrigerator Oil Refer to the nameplate of compressor
Standard Accessories Installation Manual, Operation Manual, Connection Pipes, Clamps
Drawing No. 4D057567B
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
cfm=m³/min×35.3
