SiBE37-701_B Troubleshooting by Indication on the Remote Controller
Troubleshooting 318
3.38
“
L1
”
Outdoor Unit: Malfunction of Inverter PCB
Remote
Controller
Display
L1
Applicable
Models
REYQ8P~48P
Method of
Malfunction
Detection
Malfunction is detected based on the current value during waveform output before starting
compressor.
Malfunction is detected based on the value from current sensor during synchronous operation
when starting the unit.
Malfunction
Decision
Conditions
Overcurrent (OCP) flows during waveform output.
Malfunction of current sensor during synchronous operation.
IPM failure.
Supposed
Causes
Inverter PCB (A2P)
z
IPM failure
z
Current sensor failure
z
Drive circuit failure
