Troubleshooting by Indication on the Remote Controller SiBE37-701_B
335 Troubleshooting
3.45
“
P4
”
Outdoor Unit: Malfunction of Inverter Radiation Fin
Temperature Rise Sensor
Remote
Controller
Display
P4
Applicable
Models
REYQ8P~48P
Method of
Malfunction
Detection
Resistance of radiation fin thermistor is detected when the compressor is not operating.
Malfunction
Decision
Conditions
When the resistance value of thermistor becomes a value equivalent to open or short circuited
status.
★
Malfunction is not decided while the unit operation is continued.
"
P4
" will be displayed by pressing the inspection button.
Supposed
Causes
Defect of radiator radiation fin temperature sensor
Defect of inverter PCB
Faulty inverter compressor
Faulty fan motor
Troubleshooting
Caution
Be sure to turn off power switch before connect or disconnect connector,
or parts damage may be occurred.
NO
Replace the inverter
PCB.
Measure resistance value of
the radiation fin thermistor. *
Is the thermistor
resistance value
normal?
* Disconnect the connector (X111A) from the fin
thermistor, and then check the thermistor.
The INV
compressor's
insulation resistance
is not more than
100k
Ω
.
The fan motor's
insulation resistance
is not more than
1M
Ω
.
Does the malfunction
recur when the power
supply turns ON?
YES
YES
NO
YES
YES
NO
NO
Replace the
compressor (M1C).
Replace the fan motor.
Replace the inverter
PCB.
Continue the operation.
