SiBE37-701_B Model Selection
General Information 6
4. Model Selection
VRV III Heat Recovery Series
Connectable indoor units number and capacity
Normal Series
HP 8HP 10HP 12HP 14HP 16HP 18HP 20HP
System name REYQ8P REYQ10P REYQ12P REYQ14P REYQ16P REYQ18P REYQ20P
Outdoor unit 1 REYQ8P REYQ10P REYQ12P REYQ14P REYQ16P REMQ8P REMQ8P
Outdoor unit 2 – ––––REMQ10PREMQ12P
Outdoor unit 3 – ––––––
Total number of connectable
indoor units
13 16 19 22 26 29 32
Total capacity of connectable
indoor units (kW)
10.0~26.0 12.5~32.5 15.0~39.0 17.5~45.5 20.0~52.0 22.5~58.5 25.0~65.0
HP 22HP 24HP 26HP 28HP 30HP 32HP 34HP
System name REYQ22P REYQ24P REYQ26P REYQ28P REYQ30P REYQ32P REYQ34P
Outdoor unit 1 REMQ10P REMQ12P REMQ10P REMQ12P REMQ14P REMQ16P REMQ8P
Outdoor unit 2 REMQ12P REMQ12P REMQ16P REMQ16P REMQ16P REMQ16P REMQ10P
Outdoor unit 3 – –––––REMQ16P
Total number of connectable
indoor units
35 39 42 45 48 52 55
Total capacity of connectable
indoor units (kW)
27.5~71.5 30.0~78.0 32.5~84.5 35.0~91.0 37.5~97.5 40.0~104.0 42.5~110.5
HP 36HP 38HP 40HP 42HP 44HP 46HP 48HP
System name REYQ36P REYQ38P REYQ40P REYQ42P REYQ44P REYQ46P REYQ48P
Outdoor unit 1 REMQ8P REMQ10P REMQ12P REMQ10P REMQ12P REMQ14P REMQ16P
Outdoor unit 2 REMQ12P REMQ12P REMQ12P REMQ16P REMQ16P REMQ16P REMQ16P
Outdoor unit 3 REMQ16P REMQ16P REMQ16P REMQ16P REMQ16P REMQ16P REMQ16P
Total number of connectable
indoor units
58 61 64
Total capacity of connectable
indoor units (kW)
45.0~117.0 47.5~123.5 50.0~130.0 52.5~136.5 55.0~143.0 57.5~149.5 60.0~156.0
