Specifications SiBE37-701_B
55 Specifications
Concealed Floor Standing Unit
1-1 TECHNICAL SPECIFICATIONS FXNQ20MAVE FXNQ25MAVE FXNQ32MAVE FXNQ40MAVE FXNQ50MAVE FXNQ63MAVE
Capacity Cooling kW 2.20 2.80 3.60 4.50 5.60 7.10
Heating kW 2.50 3.20 4.00 5.00 6.30 8.00
Power Input
(50Hz)
Cooling kW 0.049 0.049 0.090 0.090 0.110 0.110
Heating kW 0.049 0.049 0.090 0.090 0.110 0.110
Power Input
(60Hz)
Cooling kW 0.047 0.047 0.079 0.084 0.105 0.108
Heating kW 0.047 0.047 0.079 0.084 0.105 0.108
Casing Material Galvanised steel
Dimensions Unit Height mm 610 610 610 610 610 610
Width mm 930 930 1070 1070 1350 1350
Depth mm 220 220 220 220 220 220
Weight Unit kg 19 19 23 23 27 27
Heat
Exchanger
Dimensions
Nr of Rows 333333
Fin Pitch mm 1.50 1.50 1.50 1.50 1.50 1.50
Face Area m² 0.159 0.159 0.200 0.200 0.282 0.282
Nr of Stages 14 14 14 14 14 14
Fan Type Sirocco fan
Quantity 111111
Airflow Rate Cooling High m³/min 7.00 7.00 8.00 11.00 14.00 16.00
Low m³/min 6.00 6.00 6.00 8.50 11.00 12.00
Fan Motor Quantity 111111
Model D14B20 D14B20 2D14B13 2D14B13 2D14B20 2D14B20
Output
(high)
W151525253535
Drive Direct drive
Refrigerant Name R-410A
Cooling Sound
Pressure
High dBA 35.0 35.0 35.0 38.0 39.0 40.0
Low dBA 32.0 32.0 32.0 33.0 34.0 35.0
Piping
connections
Liquid
(OD)
Type Flare connection
Diameter mm 6.35 6.35 6.35 6.35 6.35 9.52
Gas Type Flare connection
Diameter mm 12.7 12.7 12.7 12.7 12.7 15.9
DrainDiametermm212121212121
Heat Insulation Glass Fiber/Urethane Foam
Air Filter Resin net with mold resistance
Refrigerant control Electronic expansion valve
Temperature control Microprocessor thermostat for cooling and heating
Safety devices PCB fuse
Fan motor thermal protector
Standard
Accessories
Standard Accessories Installation and operation manual
Insulation for fitting
Drain hose
Clamps
Screws
Washer
Level adjustment screw
Notes Nominal cooling capacities are based on : indoor temperature : 27°CDB, 19°CWB, outdoor temperature : 35°CDB,
equivalent refrigerant piping : 7.5m (horizontal)
Nominal heating capacities are based on : indoor temperature : 20°CDB, outdoor temperature : 7°CDB, 6°CWB,
equivalent refrigerant piping : 7.5m (horizontal)
Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
Sound pressure levels are measured at 220V
