Specifications SiBE37-701_B
43 Specifications
Concealed Ceiling Unit
1-1 TECHNICAL SPECIFICATIONS FXSQ63P7VEB FXSQ80P7VEB FXSQ100P7VEB FXSQ125P7VEB
Piping
connections
Liquid
(OD)
Type Flare connection
Diameter mm 9.52
Gas Type Flare connection
Diameter mm 15.9
Drain Diameter mm VP25 (O.D. 32 / I.D. 25)
Heat Insulation Both liquid and gas pipes
Decoration
Panel
Model BYBS71DJW1 BYBS71DJW1 BYBS125DJW1 BYBS125DJW1
Colour White (10Y9/0,5)
Dimensions
Height mm 55
Width mm 1,100 1,100 1,500 1,500
Depth mm 500
Weight kg 4.5 4.5 6.5 6.5
Drain-up Height mm 625
Air Filter Resin net with mold resistance
Refrigerant control Electronic expansion valve
Safety devices PCB fuse
PCB fuse (fan driver)
Drain pump fuse
Notes Nominal cooling capacities are based on : indoor temperature : 27°CDB, 19°CWB, outdoor temperature : 35°CDB,
equivalent refrigerant piping : 7.5m, level difference : 0m.
Nominal heating capacities are based on : indoor temperature : 20°CDB, outdoor temperature : 7°CDB, 6°CWB,
equivalent refrigerant piping : 7.5m, level difference : 0m.
Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
The sound pressure values are mentioned for a unit installed with rear suction
1-2 ELECTRICAL SPECIFICATIONS FXSQ20P7VEB FXSQ25P7VEB FXSQ32P7VEB FXSQ40P7VEB FXSQ50P7VEB
Power
Supply
Name VE
Frequency Hz 50
Voltage V 220-240
Current Minimum circuit amps
(MCA)
A 0.4 0.4 0.4 1.2 1.2
Maximum fuse amps
(MFA)
A16
Voltage
range
Minimum V -10%
Maximum V +10%
Notes Voltage range : units are suitable for use on electrical systems where voltage supplied to unit terminals is not below or
above listed range limits.
Maximum allowable voltage range variation between phases is 2%.
Select wire size based on the MCA
Instead of a fuse, use a circuit breaker
1-1 ELECTRICAL SPECIFICATIONS FXSQ63P7VEB FXSQ80P7VEB FXSQ100P7VEB FXSQ125P7VEB
Power
Supply
Name VE
Frequency Hz 50
Voltage V 220-240
Current Minimum circuit amps
(MCA)
A 1.1 1.3 1.6 2.1
Maximum fuse amps
(MFA)
A16
Voltage
range
Minimum V -10%
Maximum V +10%
Notes Voltage range : units are suitable for use on electrical systems where voltage supplied to unit terminals is not below or
above listed range limits.
Maximum allowable voltage range variation between phases is 2%.
Select wire size based on the MCA
Instead of a fuse, use a circuit breaker
