SiBE37-701_B Field Setting
Test Operation 210
“Detail of DS1-1~4, DS2-1~4 setting”
Single Use
LED
Factory Setting ( represents the position of switches)
EB****
DS1
DS2
ON
OFF
1234
DS1
1234
DS2
Allocation
Application model
Setting method ( represents the position of switches)
HEAT RECOVERY (8HP)
REYQ8PY1B
HEAT RECOVERY (10HP)
REYQ10PY1B
HEAT RECOVERY (12HP)
REYQ12PY1B
HEAT RECOVERY (14HP)
REYQ14PY1B
HEAT RECOVERY (16HP)
REYQ16PY1B
For Europe
Set DS1-4 and DS2-3 to ON.
Set DS1-4 to ON.
Set DS1-4 and DS2-2 to ON.
Set DS1-3, DS1-4 and DS2-2 to ON.
Set DS1-3, DS1-4 and DS2-3 to ON.
ON
OFF
DS1 DS2
12 34 1234
A1P (Main)
ON
OFF
DS1 DS2
12 34 1234
ON
OFF
DS1 DS2
12 34 1234
ON
OFF
DS1 DS2
12 34 1234
ON
OFF
DS1 DS2
12 34 1234
