Specifications SiBE37-701_B
41 Specifications
Concealed Ceiling Unit
1-1 TECHNICAL SPECIFICATIONS FXSQ20P7VEB FXSQ25P7VEB FXSQ32P7VEB FXSQ40P7VEB FXSQ50P7VEB
Decoration
Panel
Model BYBS32DJW1 BYBS32DJW1 BYBS32DJW1 BYBS45DJW1 BYBS45DJW1
Colour White (10Y9/0,5)
Dimensions
Height mm 55
Width mm 650 650 650 800 800
Depth mm 500
Weight kg 3.0 3.0 3.0 3.5 3.5
Drain-up Height mm 625
Air Filter Resin net with mold resistance
Refrigerant control Electronic expansion valve
Safety devices PCB fuse
PCB fuse (fan driver)
Drain pump fuse
Notes Nominal cooling capacities are based on : indoor temperature : 27°CDB, 19°CWB, outdoor temperature : 35°CDB,
equivalent refrigerant piping : 7.5m, level difference : 0m.
Nominal heating capacities are based on : indoor temperature : 20°CDB, outdoor temperature : 7°CDB, 6°CWB,
equivalent refrigerant piping : 7.5m, level difference : 0m.
Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
The sound pressure values are mentioned for a unit installed with rear suction
