Specifications SiBE37-701_B
49 Specifications
Ceiling Suspended Unit
1-1 TECHNICAL SPECIFICATIONS FXHQ32MAVE FXHQ63MAVE FXHQ100MAVE
Capacity Cooling kW 3.6 7.1 11.2
Heating kW 4.0 8.0 12.5
Power Input
(50Hz)
Cooling kW 0.111 0.115 0.135
Heating kW 0.111 0.115 0.135
Power Input
(60Hz)
Cooling kW 0.142 0.145 0.199
Heating kW 0.142 0.145 0.199
Casing Colour White (10Y9/0,5)
Dimensions Unit Height mm 195 195 195
Width mm 960 1,160 1,400
Depth mm 680 680 680
Weight Unit kg 24 28 33
Heat
Exchanger
Dimensions
Nr of Rows 2 3 3
Fin Pitch mm 1.75 1.75 1.75
Face Area m² 0.182 0.233 0.293
Nr of Stages 12 12 12
Fan Type Sirocco fan
Cooling High m³/min 12 17.5 25
Low m³/min 10 14 19.5
Fan Motor Model 3D12K1AA1 4D12K1AA1 3D12K2AA1
Output
(high)
W 62 62 130
Drive Direct drive
Refrigerant Name R-410A
Cooling Sound
Pressure
High dBA 36 39 45
Low dBA 31 34 37
Piping
connections
Liquid
(OD)
Type Flare connection
Diameter mm 6.35 9.52 9.52
Gas Type Flare connection
Diameter mm 12.7 15.9 15.9
Drain Diameter mm VP20 (I.D. 20/O.D. 26)
Heat Insulation Glass wool
Air Filter Resin net with mold resistance
Refrigerant control Electronic expansion valve
Temperature control Microprocessor thermostat for cooling and heating
Safety devices Fuse
Fan motor thermal protector
Standard Accessories Operation manual
Installation manual
Drain hose
Paper pattern for installation
Clamp metal
Insulation for fitting
Clamps
Washer
Notes Nominal cooling capacities are based on : indoor temperature : 27°CDB, 19°CWB, outdoor temperature : 35°CDB,
equivalent refrigerant piping : 7.5m (horizontal)
Nominal heating capacities are based on : indoor temperature : 20°CDB, outdoor temperature : 7°CDB, 6°CWB,
equivalent refrigerant piping : 7.5m (horizontal)
Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
