SiBE37-701_B Specifications
Specifications 24
1-1 TECHNICAL SPECIFICATIONS FXFQ63P8VEB FXFQ80P8VEB FXFQ100P8VEB FXFQ125P8VEB
Standard Accessories Installation and operation manual
Drain hose
Washer for hanging bracket
Screws
Sealing pads
Insulation for fitting
Clamp for drain hose
Installation guide
Drain sealing pad
Notes The sound pressure values are mentioned for a unit installed with rear suction
The sound power level is an absolute value indicating the power which a sound source generates.
Nominal cooling capacities are based on : indoor temperature : 27°CDB, 19°CWB, outdoor temperature : 35°CDB,
equivalent refrigerant piping : 5m, level difference : 0m.
Nominal heating capacities are based on : indoor temperature : 20°CDB, outdoor temperature : 7°CDB, 6°CWB,
equivalent refrigerant piping : 5m, level difference : 0m.
Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
The BYCQ140CW1W has white insulations. Be informed that formation of dirt on white insulations is visibly stronger and
that it is consequently not advised to install the BYCQ140W1W decoration panel in environments exposed to
concentrations of dirt.
1-2 ELECTRICAL SPECIFICATIONS FXFQ20P8VEB FXFQ25P8VEB FXFQ32P8VEB FXFQ40P8VEB FXFQ50P8VEB
Power
Supply
Name VE
Frequency Hz 50
Voltage V 220-240
Current Minimum circuit amps
(MCA)
A 0.4 0.4 0.4 0.5 0.6
Maximum fuse amps
(MFA)
A16
Full load amps (FLA) A 0.3 0.3 0.3 0.4 0.5
Voltage
range
Minimum V -10%
Maximum V +10%
Notes Voltage range : units are suitable for use on electrical systems where voltage supplied to unit terminals is not below or
above listed range limits.
Maximum allowable voltage range variation between phases is 2%.
MCA/MFA : MCA = 1.25 × FLA
MFA is smaller than or equal to 4 × FLA
Next lower standard fuse rating minimum 16A
Select wire size based on the MCA
Instead of a fuse, use a circuit breaker
1-1 ELECTRICAL SPECIFICATIONS FXFQ63P8VEB FXFQ80P8VEB FXFQ100P8VEB FXFQ125P8VEB
Power
Supply
Name VE
Frequency Hz 50
Voltage V 220-240
Current Minimum circuit amps
(MCA)
A 0.9 0.9 1.4 1.9
Maximum fuse amps
(MFA)
A16
Full load amps (FLA) A 0.7 0.7 1.1 1.5
Voltage
range
Minimum V -10%
Maximum V +10%
Notes Voltage range : units are suitable for use on electrical systems where voltage supplied to unit terminals is not below or
above listed range limits.
Maximum allowable voltage range variation between phases is 2%.
MCA/MFA : MCA = 1.25 × FLA
MFA is smaller than or equal to 4 × FLA
Next lower standard fuse rating minimum 16A
Select wire size based on the MCA
Instead of a fuse, use a circuit breaker
