SiBE37-701_B Specifications
Specifications 42
Concealed Ceiling Unit
1-1 TECHNICAL SPECIFICATIONS FXSQ63P7VEB FXSQ80P7VEB FXSQ100P7VEB FXSQ125P7VEB
Capacity Cooling kW 7.1 9.0 11.2 14.0
Heating kW 8.0 10.0 12.5 16.0
Power Input
(50Hz)
Cooling kW 0.142 0.163 0.247 0.303
Heating kW 0.130 0.151 0.235 0.291
Power Input
(60Hz)
Cooling kW 0.142 0.163 0.247 0.303
Heating kW 0.130 0.151 0.235 0.291
Casing Colour Non painted
Material Galvanised steel
Dimensions Packing Height mm 355
Width mm 1,220 1,220 1,620 1,620
Depth mm 900
Unit Height mm 300
Width mm 1,000 1,000 1,400 1,400
Depth mm 700
Weight Unit kg 35 35 46 46
Packed Unit kg 42 42 54 54
Required Ceiling Void mm >350
Heat
Exchanger
Dimensions
Length mm 740 740 1,140 1,140
Nr of Rows 3
Fin Pitch mm 1.75
Nr of Passes 7 7 11 11
Face Area m² 0.249 0.249 0.383 0.383
Nr of Stages 16
Tube type Hi-XSS (7)
Fin Fin type Symmetric waffle louvre
Treatment Hydrophilic
Fan Type Sirocco fan
Quantity 2 2 3 3
Cooling High m³/min 19.5 25 32 39
Low m³/min 16 20 23 28
Heating High m³/min 19.5 25 32 39
Low m³/min 16 20 23 28
Fan External
static
pressure
High Pa 100 100 120 120
Standard Pa 30 40 40 50
Motor Quantity 1
Model Brushless DC motor
Steps 8
Motor Speed
(cooling)
High rpm 975 1,161 1,060 1,218
Low rpm 840 960 813 920
Speed
(heating)
High rpm 975 1,161 1,060 1,218
Low rpm 840 960 813 920
Fan Motor Output
(high)
W 350
Drive Direct drive
Refrigerant Name R-410A
Sound level Cooling Sound
power
(nominal)
dBA59636166
Cooling Sound
Pressure
HighdBA37383840
LowdBA30323233
Heating Sound
Pressure
HighdBA37383840
LowdBA30323233
