Specifications SiBE37-701_B
25 Specifications
600×600 4-Way Blow Ceiling Mounted Cassette
1-1 TECHNICAL SPECIFICATIONS FXZQ20M9V1B FXZQ25M9V1B FXZQ32M9V1B FXZQ40M9V1B FXZQ50M9V1B
Capacity Cooling kW 2.2 2.8 3.6 4.5 5.6
Heating kW 2.5 3.2 4.0 5.0 6.3
Power Input
(50Hz)
Cooling kW 0.073 0.073 0.076 0.089 0.115
Heating kW 0.064 0.064 0.068 0.080 0.107
Casing Material Galvanised steel
Dimensions Unit Height mm 286
Width mm 575
Depth mm 575
Weight Unit kg 18
Heat
Exchanger
Dimensions
Nr of Rows 2
Fin Pitch mm 1.5
Face Area m² 0.269
Nr of Stages 10
Fan Type Turbo fan
Quantity 1
Cooling High m³/min 9.0 9.0 9.5 11.0 14.0
Low m³/min 7.0 7.0 7.5 8.0 10.0
Fan Motor Quantity 1
Model QTS32C15M
Output
(high)
W55
Drive Direct drive
Refrigerant Name R-410A
Sound level Cooling Sound
power
(nominal)
dBA4747495358
Cooling Sound
Pressure
HighdBA3030323641
LowdBA2525262833
Piping
connections
Liquid
(OD)
Type Flare connection
Diameter mm 6.35
Gas Type Flare connection
Diameter mm 12.7
Drain Diameter mm 26
Heat Insulation Foamed polystyrene/foamed polyethylene
Decoration
Panel
Model BYFQ60B7W1
Colour White (Ral 9010)
Dimensions
Height mm 55
Width mm 700
Depth mm 700
Weight kg 2.7
Air Filter Resin net with mold resistance
Refrigerant control Electronic expansion valve
Temperature control Microprocessor thermostat for cooling and heating
Safety devices PCB fuse
Fan motor thermal protector
Standard Accessories Installation and operation manual
Paper pattern for installation
Drain hose
Clamp metal
Washer fixing plate
Sealing pads
Clamps
Screws
Washer for hanger bracket
Insulation for fitting
Notes Nominal cooling capacities are based on : indoor temperature : 27°CDB, 19°CWB, outdoor temperature : 35°CDB,
equivalent refrigerant piping : 7.5m (horizontal)
Nominal heating capacities are based on : indoor temperature : 20°CDB, outdoor temperature : 7°CDB, 6°CWB,
equivalent refrigerant piping : 7.5m (horizontal)
Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
