Troubleshooting (OP: Unified ON/OFF Controller) SiBE37-701_B
377 Troubleshooting
Troubleshooting
Caution
Be sure to turn off power switch before connect or disconnect connector,
or parts damage may be occurred.
Is a malfunction code
displayed on the remote
controller?
Has a once
connected indoor
unit been removed
or its address
changed?
Is the power supply
for the indoor unit
displaying a
malfunction turned
on?
YES
NO
YES
NO
NO
YES
Is transmission wiring
disconnected or wired
incorrectly?
YES
NO
Is transmission with
all indoor units
malfunctioning?
YES
NO
Is the transmission
wiring with the master
controller disconnected
or wired incorrectly?
YES
NO
NO
YES
Is the master
controller's connector
for setting master
controller
disconnected.
Is the group No.
of malfunctioning
indoor units set?
YES
NO
Diagnose the cause with the
air conditioner's failure
diagnosis manual.
Reset power supply for all
optional controllers for
centralized control
simultaneously.
Turn the power supply of the
indoor unit on.
Fix the wiring correctly.
Set the group No.
correctly.
Fix the wiring correctly.
Connect the connector
correctly.
Replace the central PCB.
Replace the central PCB.
