SiBE37-701_B Option List
Appendix 442
4.2 Option Lists (Outdoor Unit)
REYQ8 ~ 16PY1
C : 3D057610A
REYQ18 ~ 32PY1
C : 3D057611C
REYQ34 ~ 48PY1
C : 3D057612C
Series
Models
Optional accessories
VRV III H/R
REYQ8PY1
REYQ10PY1
REYQ12PY1
REYQ14PY1
REYQ16PY1
Distributive
Piping
REFNET header
Model
KHRP25M33H
(Max. 8 branch)
KHRP25M33H, KHRP25M72H
(Max. 8 branch) (Max. 8 branch)
REFNET joint Model
KHRP25A22T, KHRP25A33T
KHRP25A22T, KHRP25A33T
(KHRP25A72T+KHRP25M72TP)
Central drain pan kit
Model KWC25C450 KWC25C450
Digital pressure gauge kit
Model BHGP26A1 BHGP26A1
Series
Models
Optional accessories
VRV III H/R
REYQ18PY1
REYQ20PY1
REYQ22PY1
REYQ24PY1
Distributive
Piping
REFNET header
Model
KHRP25M33H, KHRP25M72H
(Max. 8 branch) (Max. 8 branch)
KHRP25M33H, KHRP25M72H, KHRP25M73H
(Max. 8 branch) (Max. 8 branch) (Max. 8 branch)
REFNET joint Model
KHRP25A22T, KHRP25A33T
(KHRP25A72T+KHRP25M72TP)
KHRP25A22T, KHRP25A33T, (KHRP25A72T+
KHRP25M72TP), (KHRP25A73T+KHRP25M73TP)
Outdoor unit multi connection piping kit
Model BHFP26P90
Central drain pan kit
Model KWC26C280×2 KWC26C280×2
Digital pressure gauge kit
Model BHGP26A1 BHGP26A1
Series
Models
Optional accessories
VRV III H/R
REYQ26PY1
REYQ28PY1
REYQ30PY1
REYQ32PY1
Distributive
Piping
REFNET header
Model
KHRP25M33H, KHRP25M72H, KHRP25M73H
(Max. 8 branch) (Max. 8 branch) (Max. 8 branch)
REFNET joint Model
KHRP25A22T, KHRP25A33T, (KHRP25A72T+KHRP25M72TP), (KHRP25A73T+KHRP25M73TP)
Outdoor unit multi connection piping kit
Model BHFP26P90
Central drain pan kit
Model
KWC26C280
KWC26C450
KWC26C450×2
Digital pressure gauge kit
Model BHGP26A1 BHGP26A1
Series
Models
Optional accessories
VRV III H/R
REYQ34PY1
REYQ36PY1
REYQ38PY1
REYQ40PY1
REYQ42PY1
REYQ44PY1
Distributive
Piping
REFNET header
Model
KHRP25M33H, KHRP25M72H, KHRP25M73H
(Max. 8 branch) (Max. 8 branch) (Max. 8 branch)
REFNET joint Model
KHRP25A22T, KHRP25A33T, (KHRP25A72T+
KHRP25M72TP), (KHRP25A73T+KHRP25M73TP)
Outdoor unit multi connection piping kit
Model BHFP26P136
Central drain pan kit
Model
KWC26C280×2
KWC26C450
KWC26C280
KWC26C450×2
Digital pressure gauge kit
Model BHGP26A1 BHGP26A1
Series
Models
Optional accessories
VRV III H/R
REYQ46PY1
REYQ48PY1
Distributive
Piping
REFNET header
Model
KHRP25M33H, KHRP25M72H, KHRP25M73H
(Max. 8 branch) (Max. 8 branch) (Max. 8 branch)
REFNET joint Model
KHRP25A22T, KHRP25A33T, (KHRP25A72T+
KHRP25M72TP), (KHRP25A73T+KHRP25M73TP)
Outdoor unit multi connection piping kit
Model BHFP26P136
Central drain pan kit
Model KWC26C450×3
Digital pressure gauge kit
Model BHGP26A1
