SiBE37-701_B Specifications
Specifications 28
2-Way Blow Ceiling Mounted Cassette
1-1 TECHNICAL SPECIFICATIONS FXCQ20M8V3B FXCQ25M8V3B FXCQ32M8V3B FXCQ40M8V3B FXCQ50M8V3B
Air Filter Resin net with mold resistance
Air direction control Up and downwards
Refrigerant control Electronic expansion valve
Temperature control Microprocessor thermostat for cooling and heating
Safety devices PCB fuse
Fan motor thermal fuse
Drain pump fuse
Standard
Accessories
Standard Accessories Screws for fixing the paper pattern for installation
Quantity 4 4 4 4 4
Standard Accessories Washer for hanging bracket
Quantity 8 8 8 8 8
Standard Accessories Clamps
Quantity 1 1 1 1 1
Standard Accessories Installation and operation manual
Quantity 1 1 1 1 1
Standard Accessories Paper pattern for installation
Quantity 1 1 1 1 1
Standard Accessories Insulation for fitting
Quantity 2 2 2 2 2
Standard Accessories Drain hose
Quantity 1 1 1 1 1
Notes Nominal cooling capacities are based on : indoor temperature : 27°CDB, 19°CWB, outdoor temperature : 35°CDB,
equivalent refrigerant piping : 8m, level difference : 0m.
Nominal heating capacities are based on : indoor temperature : 20°CDB, outdoor temperature : 7°CDB, 6°CWB,
equivalent refrigerant piping : 8m, level difference : 0m.
Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
