Specifications SiBE37-701_B
57 Specifications
1.3 BS Units
Note:
★
1 When connecting with a 20 to 50 class indoor unit, connect to the attached pipe to the field pipe.
(Braze the connection between the attached and field pipe.)
★
2 When connecting with an indoor unit of 150 or more and 160 or less, connect to the attached pipe to the field pipe.
(Braze the connection between the attached and field pipe.)
Connection Range for BS Unit
Note:
★
Values inside brackets are based on connection of indoor units rated at maximum capacity, 200% from single outdoor units, 160% from
double outdoor units, 130% from triple outdoor units.
Model BSV4Q100PV1 BSV6Q100PV1
Power Supply 1 Phase 50Hz 200-240V 1 Phase 50Hz 200-240V
Total capacity index of connectable indoor
units
400 or less 600 or less
Capacity index of connectable indoor units
per branch
100 or less
No. of Connectable Indoor Units Max. 20 Max. 30
Casing Galvanized steel plate Galvanized steel plate
Dimensions: (H×W×D) mm 209×1053×635 209×1577×635
Sound Absorbing Thermal Insulation
Material
Foamed polyurethane, Flame resistant needle felt Foamed polyurethane, Flame resistant needle felt
Piping
Connection
Indoor
Unit
Liquid Pipes 9.5mm C1220T (brazing connection)
★
1 9.5mm C1220T (brazing connection)
Gas Pipes 15.9mm C1220T (brazing connection)
★
1 15.9mm C1220T (brazing connection)
★
2
Outdoor
Unit
Liquid Pipes 12.7mm C1220T (brazing connection) 15.9mm C1220T (brazing connection)
Suction Gas Pipes 28.6mm C1220T (brazing connection) 28.6mm C1220T (brazing connection)
★
2
HP/LP Gas Pipes 19.1mm C1220T (brazing connection) 28.6mm C1220T (brazing connection)
★
2
Weight kg 60 89
Standard Accessories
Installation manual, Attached pipe
Insulation pipe cover, Clamps
Installation manual, Attached pipe
Insulation pipe cover, Clamps
Drawing No. 4D064131A 4D064132A
Components Outdoor unit model name
Total capacity of connectable indoor
units
Number of connectable indoor
units
Indoor unit total capacity
REYQ8P 100 to 260 (400) 13 (20)
Same number of
BS units
REYQ10P 125 to 325 (500) 16 (25)
REYQ12P 150 to 390 (600) 19 (30)
REYQ14P 175 to 455 (700) 22 (35)
REYQ16P 200 to 520 (800) 26 (40)
REYQ18P 225 to 585 (720) 29 (36)
REYQ20P 250 to 650 (800) 32 (40)
REYQ22P 275 to 715 (880) 35 (44)
REYQ24P 300 to 780 (960) 39 (48)
REYQ26P 325 to 845 (1,040) 42 (52)
REYQ28P 350 to 910 (1,120) 45 (56)
REYQ30P 375 to 975 (1,200) 48 (60)
REYQ32P 400 to 1,040 (1,280) 52 (64)
REYQ34P 425 to 1,105 (1,105) 55 (55)
REYQ36P 450 to 1,170 (1,170) 58 (58)
REYQ38P 475 to 1,235 (1,235) 61 (61)
REYQ40P 500 to 1,300 (1,300)
64 (64)
REYQ42P 525 to 1,365 (1,365)
REYQ44P 550 to 1,430 (1,430)
REYQ46P 575 to 1,495 (1,495)
REYQ48P 600 to 1,560 (1,560)
