SiBE37-701_B Option List
Appendix 440
4. Option List
4.1 Option List of Controllers
Operation Control System Optional Accessories
Note:
1. Installation box (No.8) is necessary for each adaptor marked
★
.
2. Up to 2 adaptors can be fixed for each installation box.
3. Only one installation box can be installed for each indoor unit.
4. Up to 2 installation boxes can be installed for each indoor unit.
5. Installation box (No. 8) is necessary for second adaptor.
6. Installation box (No. 8) is necessary for each adaptor.
7. This adaptor is required when connecting with optional controller for centralized control.
8. BRC2A51 is also available.
Various PCBs
System Configuration
Note:
1. Installation box for adaptor must be procured on site.
No.
Type
FXFQ-P FXCQ-M
FXKQ-MA
FXDQ-NB
FXDQ-PB
FXUQ-M
FXSQ-P
FXMQ-MA
FXMQ-P FXHQ-MA FXAQ-P
FXLQ-MA
FXNQ-MA
Item
1
Remote
controller
Wireless
BRC7F634F
BRC7C62 BRC4C61 BRC4C65
BRC7C528W
BRC4C62 BRC4C65
BRC7E63W BRC7E618
BRC4C62
Wired BRC1E51
2 Wired remote controller
with weekly schedule timer
BRC1D61
3
Simplified remote
controller
—
Note 8
BRC2C51
—
Note 8
BRC2C51
—
Note 8
BRC2C51
4
Remote controller for
hotel use
— BRC3A61 — BRC3A61 — BRC3A61
5 Adaptor for wiring
★
KRP1C63
★
KRP1B61
KRP1B61
★
KRP1B56
— KRP1B61
★
KRP1C64
KRP1C3 — KRP1B61
6-1
Wiring adaptor for
electrical appendices (1)
★
KRP2A62
★
KRP2A61
KRP2A61
★
KRP2A53
★
KRP2A62
KRP2A61
★
KRP2A61
★
KRP2A62
★
KRP2A61
KRP2A61
6-2
Wiring adaptor for
electrical appendices (2)
★
KRP4AA53
★
KRP4A51
KRP4A51
★
KRP4A54
★
KRP4A53
KRP4A51
★
KRP4AA51
★
KRP4A52
★
KRP4A51
KRP4A51
7 Remote sensor
KRCS01-4B KRCS01-1
KRCS01-1
KRCS01-4B
KRCS01-1
8
Installation box for
adaptor PCB
Note 2, 3
KRP1H98
Note 2, 3
KRP1B96
—
Note 4, 6
KRP1B101
KRP1B97
Note 5
KRP4A91
—
Note 2, 3
KRP4A96
Note 3
KRP1C93
Note 2, 3
KRP4A93
—
9 Central remote controller DCS302CA61
9-1
Electrical box with earth
terminal (3 blocks)
KJB311AA
10 Unified on/off controller DCS301BA61
10-1
Electrical box with earth
terminal (2 blocks)
KJB212AA
10-2
Noise filter (for electromagnetic
interface use only)
KEK26-1A
11 Schedule timer DST301BA61
12
External control adaptor for outdoor
unit (Must be installed on indoor units)
★
DTA104A62
★
DTA104A61
DTA104A61
★
DTA104A53
— DTA104A61
★
DTA104A61
★
DTA104A62
★
DTA104A61
DTA104A61
13
Interface adaptor for
SkyAir-series
————
Note 7
DTA102A52
— ————
No. Part name Model No. Function
1 Adaptor for wiring
KRP1B56
KRP1B57
KRP1B61
KRP1B3
PCB when equipped with auxiliary electric heater in the indoor unit.
2 DIII-NET Expander Adaptor DTA109A51
Up to 1,024 units can be centrally controlled in 64 different groups.
Wiring restrictions (max. length: 1,000 m, total wiring length: 2,000 m, max. number of
branches: 16) apply to each adaptor.
No. Part name Model No. Function
1 Central remote controller
DCS302C51
DCS302CA51
(FXFQ-P)
• Up to 64 groups of indoor units (128 units) can be connected, and ON/OFF, temperature
setting and monitoring can be accomplished individually or simultaneously. Connectable up
to 2 controllers in one system.
1-1
Electrical box with earth terminal
(3 blocks)
KJB311A
2 Unified ON/OFF controller
DCS301B51
DCS301BA51
(FXFQ-P)
• Up to 16 groups of indoor units (128 units) can be turned, ON/OFF individually or
simultaneously, and operation and malfunction can be displayed. Can be used in
combination with up to 8 controllers.
2-1
Electrical box with earth terminal
(2 blocks)
KJB212A
2-2
Noise filter (for electromagnetic
interface use only)
KEK26-1
3 Schedule timer
DST301B51
DST301BA51
(FXFQ-P)
• Programmed time weekly schedule can be controlled by unified control for up to 64 groups
of indoor units (128 units). Can turn units ON/OFF twice per day.
4
Interface adaptor
for SkyAir-series
R-407C/R-22 ★DTA102A52
• Adaptors required to connect products other than those of the VRV System to the high-
speed DIII-NET communication system adopted for the VRV System.
* To use any of the above optional controllers, an appropriate adaptor must be installed on
the product unit to be controlled.
R-410A ★DTA112B51
5
Central control
adaptor kit
For UAT(Y)-K(A),
FD-K
★DTA107A55
6 Wiring adaptor for other air-conditioner ★DTA103A51
7
DIII -NET
Expander Adaptor
DTA109A51
• Up to 1024 units can be centrally controlled in 64 different groups.
• Wiring restrictions (max. length : 1,000m, total wiring length : 2,000m, max. number of
branches : 16)
apply to each adaptor.
7-1 Mounting plate KRP4A92 • Fixing plate for DTA109A51
