Specifications SiBE37-701_B
45 Specifications
1-1 TECHNICAL SPECIFICATIONS FXMQ63PVE FXMQ80PVE FXMQ100PVE FXMQ125PVE FXMQ140PVE
Capacity Cooling kW 7.1 9.0 11.2 14.0 16.0
Heating kW 8.0 10.0 12.5 16.0 18.0
Power Input
(50Hz)
Cooling kW 0.230 0.298 0.376 0.461 0.461
Heating kW 0.218 0.286 0.364 0.449 0.449
Casing Material Galvanised steel plate
Dimensions Unit Height mm 300
Width mm 1,000 1,000 1,400 1,400 1,400
Depth mm 700
Weight Unit kg 36 36 46 46 47
Heat
Exchanger
Dimensions
Nr of Rows 3
Fin Pitch mm 1.75 1.5
Face Area m² 0.249 0.249 0.383 0.383 0.383
Nr of Stages 16
Fan Type Sirocco fan
Airflow Rate Cooling High high m³/min 19.5 25 32 39 46
High m³/min 17.5 22.5 27 33 39
Low m³/min 16 20 23 28 32
Fan External
static
pressure
High Pa 200 200 200 200 140
Standard Pa 100
Low Pa 50 50 50 50 50
Motor Output
(high)
W 350 350 350 350 350
Drive Direct drive
Piping
connections
Liquid
(OD)
Type Flare connection
Diameter mm 9.52 9.52 9.52 9.52 9.52
Gas Type Flare connection
Diameter mm 15.9 15.9 15.9 15.9 15.9
Drain Diameter mm VP25 (I.D. 32/O.D. 25)
Refrigerant control Electronic expansion valve
Temperature control Microprocessor thermostat for cooling and heating
Safety devices Fuse
Fan driver overload protector
Standard Accessories Operation manual
Installation manual
Drain hose
Sealing pads
Clamps
Washer
Screws
Insulation for fitting
Clamp metal
Air discharge flange
Air suction flange
Notes Nominal cooling capacities are based on following conditions: return air temperature: 27°CDB/19°CWB; outdoor
temperature: 35°CDB; standard external static pressure: 100Pa; equivalent refrigerant piping: 7.5m (horizontal)
Nominal heating capacities are based on following conditions: return air temperature: 20°CDB; outdoor temperature:
7°CDB/6°CWB; standard external static pressure: 100Pa; equivalent refrigerant piping: 7.5m (horizontal)
Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
External static pressure is changeable in 7, 13, 14, 10 stages within the ( ) range by the remote control.
Air filter is not standard accessory, but please mount it in the duct system of the suction side. Select its colorimetric
method (gravity method) 50% or more.
