Troubleshooting (OP: Unified ON/OFF Controller) SiBE37-701_B
379 Troubleshooting
Troubleshooting
Caution
Be sure to turn off power switch before connect or disconnect connector,
or parts damage may be occurred.
Has a once connected
optional controller for
centralized control been
disconnected or its
address changed?
Is the power supply
turned on for all
optional controllers
for centralized
control?
Is the reset switch of
all optional controllers
for centralized control
set to "normal"?
Is the transmission
wiring disconnected or
wired incorrectly?
Is a centralized remote
controller or schedule
timer connected?
Are two or more unified
ON / OFF controllers
connected?
YES
NO
YES
YES
YES
NO
NO
NO
NO
NO
YES
YES
A
Is the centralized remote
controller or schedule
timer displaying a
malfunction?
Is the setting of the
unified ON / OFF
controller's switch for
setting each address
duplicated?
NO
NO
YES
YES
Reset power supply
simultaneously for all optional
controllers for centralized
control.
Turn on power supply for
all optional controllers for
centralized control.
Set the reset switch to
"normal."
Fix the wiring correctly.
Refer to failure diagnosis for
centralized remote controller
or schedule timer.
Correct the setting of the
unified ON / OFF controller's
switch for setting each
address and reset the power
supply of the unified ON /
OFF controller.
