SiBE37-701_B Troubleshooting (OP: Unified ON/OFF Controller)
Troubleshooting 384
[CHECK 4] Power Transistor Check
Perform the following procedures prior to check.
(1) Power Off.
(2) Remove all the wiring connected to the PCB where power transistors are mounted on.
[Preparation]
· Tester
* Preparing a tester in the analog system is recommended.
A tester in the digital system with diode check function will
be usable.
[Point of Measurement and Judgement Criteria]
· Measure the resistance value using a tester at each point of measurement below, 10 minutes later after power OFF.
To use analog tester:
Measurement in the resistance value mode in the range of
multiplying 1k
Ω
.
To use digital tester:
Measurement is executed in the diode check mode. ( )
No.
Point of Measurement
Judgement
Criteria
Remarks No.
Point of Measurement
Judgement
Criteria
Remarks
+– +–
1P2U
2 ~ 15k
Ω
1P2U
1.2V and over
Due to condenser charge and
so on, resistance measurement
may require some time.
2P2V 2P2V
3P2W 3P2W
4UP2
15k
Ω
and
above
(including
∞
)
Due to condenser
charge and so on,
resistance
measurement may
require some time.
4UP2
0.3 ~ 0.7V
5VP2 5VP2
6WP2 6WP2
7N3U 7N3U
8N3V 8N3V
9N3W 9N3W
10 U N3
2 ~ 15k
Ω
10 U N3
1.2V and over
Due to condenser charge and
so on, resistance measurement
may require some time.
11 V N3 11 V N3
12 W N3 12 W N3
[PCB and Circuit Diagram]
J1
J2
J3
P1 P3
N3
U
V
W
DM
P1 P2 P3
IGBT
X10A K2
L1
L2
L3
J1
J2
J3
N3
X11A
UVW
