Troubleshooting by Remote Controller SiBE37-701_B
247 Troubleshooting
2.4 Inspection Mode
Operating the INSPECTION/TEST button on the remote controller will make it possible to
check the malfunction codes, indoor unit model codes, and outdoor unit model codes while in
inspection mode.
Normal display (No display)
Inspection/test
operation
Push the button.
Malfunction code blinks when a malfunction occurs.
Unit
Malfunction code
Inspection
0
L 0
Unit
Malfunction code
Inspection
0
L 0
Inspection mode
Inspection/test
operation
Push the button.
0 7 1
F C J
Indoor unit model code display
Push the button.
Inspection/test
operation
– – –
A A 1
Outdoor unit model code display
Push the button.
Inspection/test
operation
Test operation
Test operation mode
Push the button.
Inspection/test
operation
Capacity code
Indoor unit system code
Indoor unit type code
Progression code
0 7 1...
F...
C
...
J...
Example of capacity code display
Example model Display
FXCQ25
028
FXFQ63
071
Indoor unit system code
Indoor unit type code
Display Product classification System classification
1
VRV system (VAV indoor unit)
2
VRV system
Outdoor air processing unit
F
VRV system Standard indoor unit
H
VRV system
New ceiling suspended cassette
Display Type Model
A
Wall mounted FXAQ
C
2-way blow FXCQ
E
Corner FXKQ
F
Roundflow FXFQ
H
Ceiling suspended FXHQ
J
Concealed ceiling FXSQ
P
Floor standing FXLQ
U
Concealed ceiling FXMQ
L
Concealed floor standing type
FXNQ
6
600×600 4-way blow FXZQ
3
Slim concealed ceiling FXDQ
Outdoor model code
Display Type Model
A A 1
VRV System Inverter K Series RSXYP
A A 3
R-407C VRV PLUS Series RXYP
A 9 2
VRV Heat Recovery Series RSEYP
A A 5
High COP type R-407C L Series
RSXYP-L
A A A
VRV II RXYQ-M
A A C
VRV II M/C RXYQ-MA
A A E
VRV III
Heat Pump Series RXYQ-P
Cooling Only Series RXQ-P
A 9 E
VRV III Heat Recovery Series REYQ-P
