SiBE37-701_B Specifications
Specifications 36
Slim Concealed Ceiling Unit (with Drain Pump)
1-1 TECHNICAL SPECIFICATIONS FXDQ40NBVE FXDQ50NBVE FXDQ63NBVE
Capacity Cooling kW 4.5 5.6 7.1
Heating kW 5.0 6.3 8.0
Power Input
(50Hz)
Cooling kW 0.160 0.165 0.181
Heating kW 0.147 0.152 0.168
Power Input
(60Hz)
Cooling kW 0.182 0.185 0.192
Heating kW 0.168 0.170 0.179
Casing Material Galvanised steel plate
Dimensions Unit Height mm 200 200 200
Width mm 900 900 1,100
Depth mm 620 620 620
Weight Unit kg 27 28 31
Heat
Exchanger
Dimensions
Nr of Rows 3 3 3
Fin Pitch mm 1.5 1.5 1.5
Face Area m² 0.176 0.176 0.227
Nr of Stages 12 12 12
Fan Type Sirocco fan
Airflow Rate Cooling High high m³/min 10.5 12.5 16.5
High m³/min 9.5 11.0 14.5
Low m³/min 8.5 10.0 13.0
Fan External
static
pressure
High Pa 44 44 44
Standard Pa 15 15 15
Motor Output
(high)
W 62 130 130
Drive Direct drive
Cooling Sound
Pressure
High high dBA 34 35 36
High dBA 32 33 34
Low dBA 30 31 32
Piping
connections
Liquid
(OD)
Type Flare connection
Diameter mm 6.35 6.35 9.52
Gas Type Flare connection
Diameter mm 12.7 12.7 15.9
Drain
(OD)
Diameter mm VP20 (I.D. 20/O.D. 26)
Sound absorbing insulation Foamed polyethylene
Air Filter Removable/washable/Mildew proof
Refrigerant control Electronic expansion valve
Temperature control Microprocessor thermostat for cooling and heating
Safety devices Fuse
Fan motor thermal protector
Standard
Accessories
Standard Accessories Operation manual
Installation manual
Drain hose
Sealing pads
Clamps
Washer
Insulation for fitting
Clamp metal
Washer fixing plate
Screws for duct flanges
Air filter
Product Quality Certificate
Notes Nominal cooling capacities are based on : indoor temperature : 27°CDB, 19°CWB, outdoor temperature : 35°CDB,
equivalent refrigerant piping : 7.5m (horizontal)
Nominal heating capacities are based on : indoor temperature : 20°CDB, outdoor temperature : 7°CDB, 6°CWB,
equivalent refrigerant piping : 7.5m (horizontal)
Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat.
External static pressure is changeable to set by the remote control; this pressure means : high static pressure - standard
static pressure.
The operation sound levels are conversion values in anechoic chamber. In practice, sound levels tend to be higher than
the specified values due to ambient noise or reflection. When the suction place is changed to bottom suction, sound level
will increase
