SiBE37-701_B Specifications
Specifications 16
Notes:
★
1 Indoor temp. : 27°CDB, 19.5°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
★
2 Indoor temp. : 27°CDB, 19.0°CWB / outdoor temp. : 35°CDB / Equivalent piping length : 7.5m, level
difference : 0m.
★
3 Indoor temp. : 20°CDB / outdoor temp. : 7°CDB, 6°CWB / Equivalent piping length : 7.5m, level
difference : 0m.
Model Name (Combination Unit) REYQ30P7Y1B REYQ32P7Y1B
Model Name (Independent Unit) REMQ14P7Y1B+REMQ16P7Y1B REMQ16P7Y1B+REMQ16P7Y1B
★
1 Cooling Capacity (19.5°CWB)
kcal / h 73,500 77,800
Btu / h 292,000 309,000
kW 85.5 90.5
★
2 Cooling Capacity (19.0°CWB) kW 85.0 90.0
★
3 Heating Capacity
kcal / h 81,700 86,000
Btu / h 324,000 341,000
kW 95.0 100
Casing Color
Y1 Type Ivory White 5Y7.5/1 Ivory White 5Y7.5/1
Y1E Type Light Camel 2.5Y6.5/1.5 Light Camel 2.5Y6.5/1.5
Dimensions: (H×W×D) mm 1680×1240×765+1680×1240×765 1680×1240×765+1680×1240×765
Heat Exchanger Cross fin coil Cross fin coil
Comp.
Type Hermetically sealed scroll type Hermetically sealed scroll type
Piston Displacement m³/h (13.34+10.53+10.53)×2 (13.34+10.53+10.53)×2
Number of Revolutions r.p.m (6300, 2900, 2900)×2 (6300, 2900, 2900)×2
Motor Output×Number
of Units
kW (3.2+4.5+4.5)×1+(1.9+4.5+4.5)×1 (3.2+4.5+4.5)×2
Starting Method Soft start Soft start
Fan
Type Propellor fan Propellor fan
Motor Output kW (0.35×2)+(0.35×2) (0.35×2)×2
Airflow Rate
I/s 3,833+3,833 3,833+3,833
m³/min 230+230 230+230
Drive Direct drive Direct drive
Connecting
Pipes
Liquid Pipe
φ
19.1 C1220T (Brazing connection)
φ
19.1 C1220T (Brazing connection)
Suction Gas Pipe
φ
34.9 C1220T (Brazing connection)
φ
34.9 C1220T (Brazing connection)
High and Low Pressure Gas Pipe
φ
28.6 C1220T (Brazing connection)
φ
28.6 C1220T (Brazing connection)
Pressure Equalizer Tube
φ
19.1 C1220T (Brazing connection)
φ
19.1 C1220T (Brazing connection)
Mass (Weight) kg 334+334 334+334
Safety Devices
High pressure switch, fan driver overload protector,
overcurrent relay, inverter overload protector
High pressure switch, fan driver overload protector,
overcurrent relay, inverter overload protector
Defrost Method Deicer Deicer
Capacity Control % 5~100 5~100
Refrigerant
Refrigerant Name R-410A R-410A
Charge kg 11.7+11.7 11.7+11.7
Control Electronic expansion valve Electronic expansion valve
Refrigerator Oil Refer to the nameplate of compressor Refer to the nameplate of compressor
Standard Accessories
Installation manual, Operation manual, Connection pipes,
Clamps
Installation manual, Operation manual, Connection pipes,
Clamps
Drawing No. C: 4D057809A C: 4D057810A
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3412
cfm=m³/min×35.3
