SiBE37-701_B Special Control
Function 126
3.4 Defrost Operation
[Start conditions]
Referring to the following conditions, start defrost operation.
• When there is a decrease in the coefficient of heat transfer of outdoor unit heat exchanger
• When there is a drop in the temperature of outdoor unit heat exchanger outlet (Tb)
• When the low pressure stays low for a certain amount of time (2 hours minimum)
Furthermore, the thermal continuity of outdoor unit heat exchanger is calculated by Tc, Te, and compressor loads.
Defrosting outdoor unit actuator
Symbol
Elect.
symbol
Defrost operation Operation after defrost
REYQ REMQ
Compressor 1
—
M1C M1C
REYQ8•10•12P: 232Hz+ON
REYQ14•16P: 232Hz+232Hz
REMQ8P: 210Hz
REMQ10•12P: 210Hz+ON
REMQ14•16P: 202Hz+ON+ON
REYQ8•10•12P: upper limit
124Hz(STD Holds)
REYQ14•16P: 232Hz+232Hz
REMQ8P: 210Hz
REMQ10•12P: 210Hz+ON
REMQ14•16P: 210Hz+ON+ON
Compressor 2 M2C M2C
Compressor 3 — M3C
Outdoor unit fan 1
—
M1F M1F
Outdoor unit fan 2 M2F M2F
Four way valve (Heat exchanger
switch)
20SA
Y2S
Y9S
Y3S OFF OFF
Four way valve (Dual pressure gas
pipe switch)
20SB Y8S Y2S Holds Holds
Electronic expansion valve (Main) EVM
Y1E
Y3E
Y1E 1375pls 0pls
Electronic expansion valve
(Subcooling)
EVT
Y2E
Y5E
Y3E SH control 0pls
Electronic expansion valve
(Refrigerant charge)
EVJ Y4E Y2E 80pls 80pls
Solenoid valve (Main bypass) SVE
Y5S
Y10S
Y6S ON OFF
Solenoid valve (Hot gas) SVP Y4S Y5S OFF OFF
Solenoid valve (Refrigerant
regulator liquid pipe)
SVL Y3S Y4S 0pls 0pls
Solenoid valve (Refrigerant
regulator gas vent pipe)
SVG Y1S Y1S 0pls 0pls
Solenoid valve (Refrigerant
regulator discharge pipe)
SVO Y7S Y7S 0pls 0pls
Solenoid valve (Refrigerant
regulator discharge pipe)
SVT Y6S Y8S 0pls 0pls
End conditions
REYQ8 to 16P (by unit)
• 6 min. and 30 sec.
• Tb > 11°C continues for a
period of 90 consecutive sec.
• Pc_max > 3.04MPa
REMQ8 to 12P (by unit)
• 5 min. and 30 sec.
• Tb > 11°C for a period of
10 consecutive sec.
• Pc_max > 3.04MPa
REMQ14 and16P (by unit)
• 5 min. and 30 sec.
•
Tb > 11°C for a period of 30
consecutive sec.
• Pc_max > 3.04MPa
• 30 sec.
• Pc_max>3.04MPa
&
Pcmax>2.45MPa Pcmax<2.36MPa
Pcmax>3.04MPa Pcmax<2.95MPa
OFF
FAN STEP 4
FAN STEP 6
Pcmax>2.45MPa Pcmax<2.36MPa
Pcmax>3.04MPa Pcmax<2.95MPa
OFF
FAN STEP 4
FAN STEP 6
or
or
or
or
