Special Control SiBE37-701_B
127 Function
Evaporating outdoor unit actuator
Symbol
Elect. symbol
Defrost operation Operation after defrost
REYQ REMQ
Compressor 1
—
M1C M1C
REYQ8•10•12P: 232Hz+ON
REYQ14•16P: 232Hz+232Hz
REMQ8P: 210Hz
REMQ10•12P: 210Hz+ON
REMQ14•16P: 210Hz+ON+ON
Upper limit 124Hz (STD Holds)
REYP400•480A: 232Hz+232Hz
REMP224A: 210Hz
REMP280•335A: 210Hz+ON
REMP400•450A:
210Hz+ON+ON
Compressor 2 M2C M2C
Compressor 3 M3C M3C
Outdoor unit fan 1
—
M1F M1F
Fan control Fan control
Outdoor unit fan 2 M2F M2F
Four way valve (Heat exchanger
switch)
20SA
Y2S
Y9S
Y3S ON ON
Four way valve (Dual pressure gas
pipe switch)
20SB Y8S Y2S Holds Holds
Electronic expansion valve (Main) EVM
Y1E
Y3E
Y1E PI control PI control
Electronic expansion valve
(Subcooling)
EVT
Y2E
Y5E
Y3E SH control 0pls
Electronic expansion valve
(Refrigerant charge)
EVJ Y4E Y2E 80pls 80pls
Solenoid valve (Main bypass) SVE
Y5S
Y10S
Y6S OFF OFF
Solenoid valve (Hot gas) SVP Y4S Y5S OFF OFF
Solenoid valve (Refrigerant
regulator liquid pipe)
SVL Y3S Y4S 0pls 0pls
Solenoid valve (Refrigerant
regulator gas vent pipe)
SVG Y1S Y1S 0pls 0pls
Solenoid valve (Refrigerant
regulator discharge pipe)
SVO Y7S Y7S 0pls 0pls
Solenoid valve (Refrigerant
regulator discharge pipe)
SVT Y6S Y8S 0pls 0pls
Cooling indoor unit actuator Defrost operation
Fan
Thermo. ON unit Remote controller setting
Unit not in operation OFF
Thermo. OFF unit Remote controller setting
Electronic expansion valve
Thermo. ON unit Normal opening degree
Unit not in operation 0pls
Thermo. OFF unit 0pls
Heating indoor unit actuator
Defrost operation
REYQ REMQ
Fan
Thermo. ON unit LL LL
Unit not in operation OFF OFF
Thermo. OFF unit LL LL
Electronic expansion valve
Thermo. ON unit 160pls 224pls
Unit not in operation 0pls 0pls
Thermo. OFF unit 160pls 224pls
Cooling BS unit actuator Elect. symbol Defrost operation
Electronic expansion valve (EVH) Y4E 0pls
Electronic expansion valve (EVL) Y5E 760pls
Electronic expansion valve (EVHS) Y2E 0pls
Electronic expansion valve (EVLS) Y3E 480pls
Electronic expansion valve (EVSC) Y1E 0pls
Heating BS unit actuator Elect. symbol Defrost operation
Electronic expansion valve (EVH) Y4E 760pls
Electronic expansion valve (EVL) Y5E 0pls
Electronic expansion valve (EVHS) Y2E 60pls
Electronic expansion valve (EVLS) Y3E 0pls (REYQ8~16P) 60pls (REMQ8~16P)
Electronic expansion valve (EVSC) Y1E 0pls (PI control for cool/heat concurrent operation)
